NO PART NAME NO PART NAME NO PART NAME
1 BASE CAB AS 7 PIPE HOT 13 BASE COMP AS
2 COMPRESSOR 8 DRYER AS 14 BRACKET EARTH
3 P-RELAY AS 9 PIPE SUC AS 15 POWER CORD AS
4 PIPE VAPORI AS 10 PIPE SUC CONN 16 ABSORBER PIPE A
5 ABSORBER PIPE B 11 BOX POWER AS
6 PIPE S *PLT 12 HARNESS EARTH
4. MACHINE ROOM VIEW AND PART LIST
-4-
