Dispenser Control Function
Control Object
Dispenser SW
Water/Ice Button
Lock Ice Maker Button
Freezer Door SW
Dispenser Lamp
Crusher Motor
Flat Solenoid
Crusher Solenoid
Dispenser Water Valve
Contents Remark
1) Water/Ice Selection Button
Progress : Water Ice Cube Crushed Ice Water
2) Lock Ice Maker Button
Start by pushing "Lock Ice Maker" button
" Lock Icer Maker" is "ON",
The Icon & Box of "Cube Ice"/"Crushed Ice" disappear,
"Water"Icon & Box is always "ON"
Stop by pushing "Lock Ice Maker" button again.
"Lock Icer Maker" Icon is "OFF",
The Icon & Box of"Cube Ice"/"Crushed Ice"is "OFF",
"Water"Icon & Box is "ON".
3) Display
- Initial Mode : Wateer ICON & Letter is "ON".
- A rectangle Line around the icon lights up to indicate your selection is on.
- The Icon of water, Ice Cube, Crushed Ice is always " ON".( Exception, Dispenser
S/W Error)
- When pushing ' Lock Ice Maker':
Lock Ice Maker LED is "ON" , The letters of crushed, cube Ice are "OFF"
- There is no input during 1 hour, Dispeser transform into Water Mode.
Input
* Initial Mode : Water
* Pushing the dispenser value, water/Ice cube/crushed Ice is dispensed as your selection.
!
@
