Daewoo FRS-2021 - Fan Function

Fan Function
How It Works ;
ON Condition OFF Condition
MICOM Port MICOM Port
Control
Object
Control
Method
31
32
33
IC Collector
31
32
33
IC Collector
Low (10V)
operation
5V
0V
0V
10.35V 0V
Mid (12V)
operation
0V
5V
0V
12.19V 0V
F-FAN
High (14V)
operation
0V
0V
0V
14.38V
5V
5V
5V
0V
ON Condition OFF Condition
MICOM PORT
MICOM Port
Control
Object
Control
Method
39
40
41
IC Collector
39
40
41
IC Collector
Low (10V)
operation
0V
5V
5V
10.38V 0V
Mid (12V)
operation
5V
0V
5V
12.24V 0V
R-FAN
High (14V)
operation
5V
5V
5V
14.42V
0V
0V
0V
0V
ON Condition OFF Condition
MICOM Port MICOM Port
Control
Object
Control
Method
37 38
IC Collector
37 38
IC Collector
High (14V)
operation
0V 0V 14.54V 0V
C-FAN
Low (10V)
operation
5V 0V 10.45V
5V 5V
0V
- 37 -
