5) Freezer (Refrigerator) Pockets
6) F-Louver Parts Disassembling.
* Hold the middle and pull up slightly.
(Assembling order is the reverse of disassembling.)
- Ref Pockets are the same way.
* Open the door fully and remove the shelves.
* Remove screw cap on the bottom of light cover and
unscrew two screws with a (+) driver to separate
the light cover. [Refer to 1) Exchanging F-lights]
* Seperate F-lights housing & Heater housing
(Eva front cover) from the interior side terminals.
* Remove screw caps on F-louver A/B with a (-) driver
and then unscrew three screws with a (+) driver.
* Hold both end and pull forward smoothly.
- 45 -
