16
※Remove front bottom cover first, if it is attached.
If the refrigerator can not enter
the door, follow these steps.
1
Unscrew top hinge cover with a screw
driver.
Insert a thin screw driver into the side
groove of the cover to remove.
2
Turn top hinge fastener counterclockwise
3~4 times. (Just make it loose ; do not
remove.)
Disconnect the harness wires.
Loosen hinge screws for several turn.
(Just make them loose ; do not remove.)
3
Lift up the front of hinge to remove. ( After
the hinge is removed the door can fall
down forward. Be careful !)
4
Lift the door straight up to remove.
Removing Freezer Door
To Next Page
