1. Display control
2. “FREEZER SET” Button
1) Temperature control of freezer compartment
2) 5 step mode of successive temperature mode.
3) Initial mode by power input : “Medium(-19C)”
※Whenever pressing button, setting is repeated in the order of
-19C → -21C → -25C → -15C → -17C
INPUT CONTROL OBJECT
CONTENTS
Front PCB button
FREEZER SET, REFRIGERATOR SET
SUPER FREEZER, SUPER REFRIGERATOR
RESET FILTER, WATER / ICE, ICE MAKER LOCK
,LOCK
FCP LED
3. “SUPER FREEZER” Button
When this mode is chosen, the LED is ON.
After six month, LED ONFILTER CHANGE LED
DialWATER / CUBED ICE/ CRUSHED ICE LED
Always ONFUZZY, DEODORIZER LED
Dial
SUPER FREEZER,SUPER
REFRIGERATOR LED
Initial mode : Freezer & Refrigerator set→
Medium (-19C/2C)
88 DISPLAY (SET TEMP.)
ControlFCP-LED
4-1-2. FRS-20DD / 20FD / 24DD / 24FD ( Dispenser Model )
-25-21-19-17-15Temp indication
HIGHMID HIGH
MIDLOW MIDLOWTemperature Chang
