Daewoo FRS-20BD - Error Display

20
1. How to start
: Push “SUPER FREEZER” button 5 times while pushing “FREEZER SET” button
at the same time.
2. How to stop
1) Push “FREEZER SET” button 1 time.
2) It stops automatically in 4 minutes from the start.
3. All the error codes are reset if they turn to be normal.
4. Error display
INPUT CONTROL OBJECT
CONTENTS REMARKS
Temperature Control Buttons LED
Display forced defrost mode for A/S.
d2
Display Full-Down mode.
Co
Return after defrosting : abnormal or defective.
F3
Cycle : abnormal or defective.
c1
F-Door switch : defective.
dF
R-Door switch : defective.
dr
D-sensor : disconnection, short.
d1
RT-sensor : disconnection, short.
rt
R-sensor : disconnection, short.
r1
F-sensor : disconnection, short.
F1
DisplayCONTENTS
4-8. Error Display
4-8-1. FRS-20BD / 24BD ( Basic Model )
