EXPLODED VIEW AND PARTS LIST
2) KOR-860A1A
REF NO PART CODE PART NAME DESCRIPTION Q'TY SUPPLY
A00 3511710720 DOOR AS KOR-86050S 1 O
B00 PKCPSWNF00 CONTROL-PANEL AS KOR-860A0A 1 O
F01 3510801430 CABINET PCM T0.6 GE 1 O
F02 7S312X40A1 SPECIAL SCREW T1 TRS 4*10 SE MFZN 3 O
F03 3516109200 CAVITY WELD AS KOR-86150S 1 O
3516109700 CAVITY JOINT AS KOR-86150S 1 O
F04 7112401011 SCREW TAPPING T1 TRS 4*10 MFZN 1 O
F05 7122401211 SCREW TAPPING T2S TRS 4*12 MFZN 1 O
F06 7121300611 SCREW TAPPING T2S PAN 3X6 MFZN 1 O
F07 3518902600 THERMOSTAT OFF : 90 ON : 60 H #187 1 O
F08 7112401011 SCREW TAPPING T1 TRS 4*10 MFZN 1 O
F09 35113YCNS5 CORD POWER AS 3X0.75 40X40 120-RTML 1 O
F10 4413A90012 CLAMP POWER CORD NYLON66 1 O
F11 7122401211 SCREW TAPPING T2S TRS 4*12 MFZN 1 O
F12 3518606100 NOISE-FILTER DWLF-M13 1 O
F13 4414A25110 FUSE 250V 15A 65TS 1 O
F14 7112401011 SCREW TAPPING T1 TRS 4X10 MFZN 1 O
F15 7121403011 SCREW TAPPING T2S PAN 4X30 MFZN 2 O
F16 3963821600 MOTOR SHADED POLE 120V 21W OEM-10DWX1-A07 1 O
F17 3512517000 GUIDE WIND PP 1 O
F18 3511800300 FAN PP+30%GLASS 1 O
F19 3518002200 MAGNETRON 2M218H(MF) I 1 O
F20 3516004000 SPECIAL SCREW T2 BOLT FLANGE 5X12 DACRO 1 O
F21 7272400811 SCREW TAPTITE TT3 TRS 4X8 MFZN 1 O
F22 3513003200 HOLDER HV CAPACITOR SECC T0.6 1 O
F23 3518301800 CAPACITOR HV 2100VAC 0.82uF #187 1 O
F24 3518400400 DIODE HV HVR-1X-3AB 12KV #187 1 O
F25 3518114700 TRANS HV JMOT-N90A0-86T 1 O
F26 3516003700 SPECIAL SCREW TT3 HEX 4X8 FLG MFZN 4 O
F27 3510311900 BASE SBHG T0.8 1 O
F28 7112401011 SCREW TAPPING T1 TRS 4*10 MFZN 5 O
F29 3512100900 FOOT PP DASF-130 2 O
F30 7272400811 SCREW TAPTITE TT3 TRS 4X8 MFZN 1 O
F31 3515201101 STOPPER HINGE *U SCP-1 T2.5 1 O
F32 7122401211 SCREW TAPPING T2S TRS 4X12 MFZN 1 O
F33 4415A17352 SW MICRO VP-533A-OF SPNO #187 200G 1 O
F34 4415A66600 SW MICRO VP-532A-OF/SZM-V16-FA-62 1 O
F35 4415A17352 SW MICRO VP-533A-OF SPNO #187 200G 1 O
F36 3513702600 LEVER LOCK POM 1 O
F37 3513811700 LOCK POM 1 O
F38 3513601500 LAMP BL 125V 25W T25 C5A H187 1 O
F39 7121400611 SCREW TAPPING T2S PAN 4X6 MFZN 1 O
F40 3966820200 MOTOR SYNCRO 120V 2W GM-16-12F17 1 O
F41 7272400811 SCREW TAPTITE TT3 TRS 4X8 MFZN 1 O
F42 3511406200 COVER WAVE GUIDE HEATPROOF PP 1 O
F43 4418D10032 COUPLER ZAREC 1 O
3512510600 GUIDE ROLLER AS KOR-61150S 1 O
F44 3514700900 ROLLER TEFLON 3 X
F45 3512509200 GUIDE ROLLER PP 1 X
F46 3517203500 TRAY GLASS 1 O
✔ Caution:
In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the
latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr)
