-45-
Bill of Materials
LOC PARTS CODE PARTS NAME PARTS DESCRIPTION
JK201 4859118050 JACK PIN DPSE-9926S
JK202 4859105340 JACK S-VHS DSW-10 (STRAIGHT)
JK203 4859201860 CONN D-SUB SHD-015-C0925 (15P ST FEMALE)
JK206 4959102340 JACK PHONE SPJ-358H(3.5 STRAIGHT)
JK208 4859117950 JACK PIN DPSE-0415S
JK213 4859118350 JACK PIN SH4-28A1PB STRAIGHT
JK401 4859201760 CONN D-SUB SHD-009-20105 (9P ST FEMALE)
JK601 4859101880 JACK OPTICAL SENSOR SHO-DQT-021 (16MBPS)
LC814 58C0000116 COIL BEAD HC-3550R
M101 485A117570 SHIELDRON 45X20X4(T)
M372 4956800200 CLAMP WIRE WS-A-2-19
M381 4853835300 FRAME SIDE T SECC T1.2
M3811 7178300851 SCREW TAPPTITE TT2 WAS 3X8 MFZN 3CR
M382 4853835400 FRAME SIDE B SECC T1.6
M3821 7178300851 SCREW TAPPTITE TT2 WAS 3X8 MFZN 3CR
M383 4853835100 FRAME SUPPORT R SECC T1.0
M384 4853835200 FRAME SUPPORT L SECC T1.0
M38P1 7178300851 SCREW TAPPTITE TT2 WAS 3X8 MFZN 3CR
M38P2 7178300851 SCREW TAPPTITE TT2 WAS 3X8 MFZN 3CR
P202 4859290520 CONN WAFER 20017WR-04A
P501 4859200420 CONN WAFER(PIN HEADER) 4602-10MV2-60-1 PLUG 10P ST
P601 4959260620 CONN WAFER SMAW250-03
P602 4959260820 CONN WAFER SMAW250-02
P801 4959203820 CONN WAFER SMW250-15
P801A 4850715S06 CONNECTOR SMH250-15+SMH250-15+ULW=200
SW401 5S50101Z90 SW TACT THVV502GDA
TU101 4859700850 TUNER DIGITAL TDVF-H053F
X101 5XJ27R00AC CRYSTAL QUARTZ HC-49/S 27.000MHZ 15PF 20PPM
X402 5XJ24R00NE CRYSTAL QUARTZ HC-49/S 24.000MHZ 22PF 30PPM
X501 5XJ16R00JE CRYSTAL QUARTZ HC-49/S 16.000MHZ 18PF 30PPM
CC101 HCFK104ZBA C CHIP CERA 50V Y5V 0.1MF Z 1608
CC102 HCQK471JBA C CHIP CERA 50V CH 470PF J 1608
CC104 HCBK103KBA C CHIP CERA 50V X7R 0.01MF K 1608
CC129 HCFK104ZBA C CHIP CERA 50V Y5V 0.1MF Z 1608
CC130 HCFK104ZBA C CHIP CERA 50V Y5V 0.1MF Z 1608
CC131 HCFK104ZBA C CHIP CERA 50V Y5V 0.1MF Z 1608
CC132 HCFK104ZBA C CHIP CERA 50V Y5V 0.1MF Z 1608
CC133 HCFK104ZBA C CHIP CERA 50V Y5V 0.1MF Z 1608
CC134 HCFK104ZBA C CHIP CERA 50V Y5V 0.1MF Z 1608
CC135 HCFK104ZBA C CHIP CERA 50V Y5V 0.1MF Z 1608
CC136 HCFK104ZBA C CHIP CERA 50V Y5V 0.1MF Z 1608
CC138 HCQK101JBA C CHIP CERA 50V CH 100PF J 1608
CC140 HCQK101JBA C CHIP CERA 50V CH 100PF J 1608
CC141 HCQK101JBA C CHIP CERA 50V CH 100PF J 1608
CC142 HCFK104ZBA C CHIP CERA 50V Y5V 0.1MF Z 1608
CC144 HCFK104ZBA C CHIP CERA 50V Y5V 0.1MF Z 1608
CC149 HCQK101JBA C CHIP CERA 50V CH 100PF J 1608
CC158 HCQK470JBA C CHIP CERA 50V CH 47PF J 1608
CC201 HCQK330JBA C CHIP CERA 50V CH 33PF J 1608
CC202 HCQK330JBA C CHIP CERA 50V CH 33PF J 1608
CC225 HCFK104ZBA C CHIP CERA 50V Y5V 0.1MF Z 1608
CC227 HCFK104ZBA C CHIP CERA 50V Y5V 0.1MF Z 1608
CC250 HCBF224KBA C CHIP CERA 16V X7R 0.22MF K 1608
CC251 HCBF224KBA C CHIP CERA 16V X7R 0.22MF K 1608
CC262 HCFK104ZBA C CHIP CERA 50V Y5V 0.1MF Z 1608
CC271 HCFK104ZBA C CHIP CERA 50V Y5V 0.1MF Z 1608
CC274 HCFK104ZBA C CHIP CERA 50V Y5V 0.1MF Z 1608
CC277 HCFK104ZBA C CHIP CERA 50V Y5V 0.1MF Z 1608
CC280 HCFK104ZBA C CHIP CERA 50V Y5V 0.1MF Z 1608
CC283 HCFK104ZBA C CHIP CERA 50V Y5V 0.1MF Z 1608
CC286 HCFK104ZBA C CHIP CERA 50V Y5V 0.1MF Z 1608
CC303 HCQK331JBA C CHIP CERA 50V CH 330PF J 1608
CC304 HCFK104ZBA C CHIP CERA 50V Y5V 0.1MF Z 1608
CC305 HCQK331JBA C CHIP CERA 50V CH 330PF J 1608
CC307 HCQK331JBA C CHIP CERA 50V CH 330PF J 1608
CC308 HCFK104ZBA C CHIP CERA 50V Y5V 0.1MF Z 1608
CC309 HCQK331JBA C CHIP CERA 50V CH 330PF J 1608
LOC PART CODE PART NAME DESCRIPTION
CC310 HCFK104ZBA C CHIP CERA 50V Y5V 0.1MF Z 1608
CC311 HCQK331JBA C CHIP CERA 50V CH 330PF J 1608
CC312 HCFK104ZBA C CHIP CERA 50V Y5V 0.1MF Z 1608
CC313 HCQK331JBA C CHIP CERA 50V CH 330PF J 1608
CC314 HCFK104ZBA C CHIP CERA 50V Y5V 0.1MF Z 1608
CC315 HCQK331JBA C CHIP CERA 50V CH 330PF J 1608
CC316 HCFK104ZBA C CHIP CERA 50V Y5V 0.1MF Z 1608
CC318 HCFK104ZBA C CHIP CERA 50V Y5V 0.1MF Z 1608
CC319 HCQK331JBA C CHIP CERA 50V CH 330PF J 1608
CC320 HCFK104ZBA C CHIP CERA 50V Y5V 0.1MF Z 1608
CC321 HCQK331JBA C CHIP CERA 50V CH 330PF J 1608
CC322 HCFK104ZBA C CHIP CERA 50V Y5V 0.1MF Z 1608
CC323 HCQK331JBA C CHIP CERA 50V CH 330PF J 1608
CC324 HCFK104ZBA C CHIP CERA 50V Y5V 0.1MF Z 1608
CC325 HCQK331JBA C CHIP CERA 50V CH 330PF J 1608
CC326 HCFK104ZBA C CHIP CERA 50V Y5V 0.1MF Z 1608
CC327 HCQK331JBA C CHIP CERA 50V CH 330PF J 1608
CC328 HCFK104ZBA C CHIP CERA 50V Y5V 0.1MF Z 1608
CC329 HCQK331JBA C CHIP CERA 50V CH 330PF J 1608
CC330 HCFK104ZBA C CHIP CERA 50V Y5V 0.1MF Z 1608
CC331 HCQK331JBA C CHIP CERA 50V CH 330PF J 1608
CC332 HCFK104ZBA C CHIP CERA 50V Y5V 0.1MF Z 1608
CC333 HCQK331JBA C CHIP CERA 50V CH 330PF J 1608
CC334 HCFK104ZBA C CHIP CERA 50V Y5V 0.1MF Z 1608
CC335 HCQK331JBA C CHIP CERA 50V CH 330PF J 1608
CC411 HCFF474ZBA C CHIP CERA Y5V 16V 0.47MF Z 1608
CC412 HCBK102KBA C CHIP CERA 50V X7R 1000PF K 1608
CC413 HCFK104ZBA C CHIP CERA 50V Y5V 0.1MF Z 1608
CC414 HCBK102KBA C CHIP CERA 50V X7R 1000PF K 1608
CC415 HCFF474ZBA C CHIP CERA Y5V 16V 0.47MF Z 1608
CC416 HCFK104ZBA C CHIP CERA 50V Y5V 0.1MF Z 1608
CC417 HCFF474ZBA C CHIP CERA Y5V 16V 0.47MF Z 1608
CC418 HCFF474ZBA C CHIP CERA Y5V 16V 0.47MF Z 1608
CC419 HCBK102KBA C CHIP CERA 50V X7R 1000PF K 1608
CC420 HCFK104ZBA C CHIP CERA 50V Y5V 0.1MF Z 1608
CC421 HCFF474ZBA C CHIP CERA Y5V 16V 0.47MF Z 1608
CC422 HCQK331JBA C CHIP CERA 50V CH 330PF J 1608
CC423 HCFK104ZBA C CHIP CERA 50V Y5V 0.1MF Z 1608
CC424 HCQK331JBA C CHIP CERA 50V CH 330PF J 1608
CC429 HCFF474ZBA C CHIP CERA Y5V 16V 0.47MF Z 1608
CC430 HCBK102KBA C CHIP CERA 50V X7R 1000PF K 1608
CC431 HCFK104ZBA C CHIP CERA 50V Y5V 0.1MF Z 1608
CC434 HCFK104ZBA C CHIP CERA 50V Y5V 0.1MF Z 1608
CC435 HCFF474ZBA C CHIP CERA Y5V 16V 0.47MF Z 1608
CC436 HCBK102KBA C CHIP CERA 50V X7R 1000PF K 1608
CC439 HCFF474ZBA C CHIP CERA Y5V 16V 0.47MF Z 1608
CC440 HCBK102KBA C CHIP CERA 50V X7R 1000PF K 1608
CC501 HCQK180JBA C CHIP CERA 50V CH 18PF J 1608
CC502 HCQK180JBA C CHIP CERA 50V CH 18PF J 1608
CC503 HCFK104ZBA C CHIP CERA 50V Y5V 0.1MF Z 1608
CC606 HCFK104ZBA C CHIP CERA 50V Y5V 0.1MF Z 1608
CC607 HCFF474ZBA C CHIP CERA Y5V 16V 0.47MF Z 1608
CC608 HCFF474ZBA C CHIP CERA Y5V 16V 0.47MF Z 1608
CC609 HCBK102KBA C CHIP CERA 50V X7R 1000PF K 1608
CC612 HCFK104ZBA C CHIP CERA 50V Y5V 0.1MF Z 1608
CC625 HCFK104ZBA C CHIP CERA 50V Y5V 0.1MF Z 1608
CC626 HCFK104ZBA C CHIP CERA 50V Y5V 0.1MF Z 1608
CC628 HCFK104ZBA C CHIP CERA 50V Y5V 0.1MF Z 1608
CC629 HCFK104ZBA C CHIP CERA 50V Y5V 0.1MF Z 1608
CC640 HCBK102KBA C CHIP CERA 50V X7R 1000PF K 1608
CC641 HCBK102KBA C CHIP CERA 50V X7R 1000PF K 1608
CC643 HCFK104ZBA C CHIP CERA 50V Y5V 0.1MF Z 1608
CC648 HCFK104ZBA C CHIP CERA 50V Y5V 0.1MF Z 1608
CC649 HCFK104ZBA C CHIP CERA 50V Y5V 0.1MF Z 1608
CC658 HCFK104ZBA C CHIP CERA 50V Y5V 0.1MF Z 1608
CC667 HCFK104ZBA C CHIP CERA 50V Y5V 0.1MF Z 1608
CC668 HCFK104ZBA C CHIP CERA 50V Y5V 0.1MF Z 1608
CC669 HCFK104ZBA C CHIP CERA 50V Y5V 0.1MF Z 1608
LOC PART CODE PART NAME DESCRIPTION
5) COMMON PARTS
To Next Page
