Daewoo Mega 200-VTC - Page 189

022-00028AE Operation and Maintenance Manual Specifications 7-5
WORKING RANGE AND DIMENSIONS
Figure 2 illustrates exterior machine dimensions and working range of machine when it is equipped with a
standard bucket.
I
H
B
D
A
E
C
F
BFO0020L
Figure 2
