Daewoo NC-8913 - Page 11

TroubleShootingGuide
Front Section
1
3
3
4
5
6
7
8
9
1
3
3
4
5
6
7
8
9
AM/FM Speaker sound
no
1.Check AM ANT and CN001
2.FM ANT: CN101.
3.Check IC101 VCC 6pin: 4.7V.
4.Check PC101
5.Check L008 and L009.
6.Check output signal pin of IC101 of 13pin
and 14pin.
Change to CD function
no
1.Check CN704
2.Check IC701 of 38pin and 39pin and 40pin
41pin and 44pin.
Yes
Yes
Phones sound
no
1.Check J701
2.Check IC702(IL4560D)
3.Check CN700
