Daewoo NC-8913 - Appendix - Electrical Part List; PCB Main Assembly Parts; PCB Front Assembly Parts

APPENDIX-ELECTRICALPARTLIST
1
2
3
4
5
6
7
9
9
1
2
3
4
5
6
7
9
9
Location Part Code Part Name Remark
D900
、
D901
、
D902
、
D903 DIN5402--- DIODE IN5402 Only NC-8913DU/DE, NC-8915DU/DE
D900
、
D901
、
D902
、
D903 DRL202---- DIODE RL202 Only NC-8911DU/DE
D904
、
D905
、
D906
、
D907 DRL202---- DIODE RL202
HZ900 DMTZ10B--- DIODE ZENER CHIP UDZ10B 17X12
HQ802
、
HQ803
、
HQ808
、
HQ809 TZTD1304-- TR CHIP KTD1304
HQ806
、
HQ807
、
HQ818 TZRA107S-- TR CHIP KRA107S
HQ819
、
HQ902
、
HQ903 TZRC107S-- TR CHIP KRC107S
HQ900 TZTC3875S- TR CHIP KTC3875Y
HQ901 TZRA111S-- TR CHIP KRA111S
IC400 1SC7314S-- IC AUDIO PROCESSOR SC7314S
IC401 1NJM4558M- IC NJM4558M Only NC-8913DU/DE, NC-8915DU/DE
IC402 1NJM4558M- IC NJM4558M Only NC-8913DU/DE, NC-8915DU/DE
IC800 1TDA7292-- IC TDA7292 Only NC-8913DU/DE, NC-8915DU/DE
IC801 1TDA7292-- IC TDA7292 Only NC-8913DU/DE, NC-8915DU/DE
IC801 1CD7269ACZ IC CD7269ACZ Only NC-8911DU/DE
IC900 1CW7809--- IC CW7809
Q800 TZTC3198Y
- TR KTC3198Y (2SC5343) AUTO Only NC-8913DU/DE,NC-8915DU/DE
Q816 TZTC3198Y- TR KTC3198Y (2SC5343) AUTO
Q900 TZTA1273Y- TR KTA1273Y (A966Y) (KSA928A-Y) (STB1277Y)
Q902 TZTA1274Y- TR KTA1274Y
Location Part Code Part Name Remark
LC701 DH93390501 LCD H93390501PMN
HQ013
、
HQ014
、
HQ709 TZRA111S-- TR CHIP KRA111S
HQ015
、
HQ016
、
HQ703
、
HQ705
HQ706
、
HQ707
、
HQ708 TZRC111S-- TR CHIP KRC111S
IC101 1TA2111N-- IC
TA2111N
IC102 1SA1117S33 IC REGULATOR SA1117BH-3.3(SOT-223-3L)
IC700 1CS9255--- IC CS9255
IC701 1CA6808F-- IC MICOM CA6808F
IC702 1IL4560D-- IC H/P AMP IL4560D(SOIC)
IC703 1SIR8330L9 IC RMC SIR8330L9M2B4
IC704 1SA1117S33 IC REGULATOR SA1117BH-3.3(SOT-223-3L)
J701 F736300013 JACK H/P TC38-933-01
LD701
、
LD702
DBZ-BZ52V1G LED BACKLIGHT BZ-BZ52V1-M36-TBS18A
SW701
、
SW702
、
SW703
、
SW704
SW705
、
SW706
、
SW707
、
SW708
SW709
、
SW710
、
SW711
、
SW712
5S50101Z67A-2 SW TACT THVV502GAA
CF001
SFU455B--- FILTER CERA
SFU455B
CF002 5PLT107MA5 FILTER CERA
LT10.7MA5(SZ)
CF003
FP107MG77- FILTER CERA
JT107MG77
DZ001 DZTZ4R7B-- DIODE ZENER UZ-4.7B 52MM TAPPING
HZ701
DMTZ5R6B-- DIODE ZENER CHIP UDZ5.6B 17X12
HZ702 DMTZ3R3B- DIODE ZENER CHIP UDZ3.3B 17X12
R701 RD-4Z101J- R CARBON FILM 1/4 100 OHM J
R702 RD-4Z560J- R CARBON FILM 1/4 56 OHM J
L001 FLA139K005 COIL FM ANT
5mm X 0.8mm X 4.5T(1.3uH)
L
002 FLR119K001 COIL FM RF
5mm X 0.8mm X 3.5T(1.1uH)
L003 FLO838K002 COIL FM OSC
5mm X 0.8mm X 2.5T(0.83uH)
L008 F110AYW001 IFT AM TF10-19
L009 FLO361K003 COIL AM OSC
ML10-37B
L011 FLA361K012 COIL AM ANT IFT-7SB-4251-00-LF
L012 FCPZ561K01 COIL PEAKING AL0305-561K-LF
L701 FLC260K006 COIL CHOKE NTC10*5*5-260M
PC101 FC134P001D
PVC TU-CAP 20-126P 20X20A
Q002
、
Q003
TZS9018H-- TR S9018H(TO-92)
Q004 TZSK544E-- TR 2SK544E-AC
Q005
、
Q701
TZS8550Y-- TR S8550
Q006
、
Q702
TZTC8050-D
TR KTC8050-D
VR701 FSH3024A06 SW ENCODER REO123PVB30F INBI-2-24PCE/D
X701
、
X702
5XA32R768CCQ X-TAL SF-32.768-JU3820
Location Part Code Part Name Remark
J800 F736900016 JACK SPEAKER WP-813-030 Only NC-8913DU/DE, NC-8915DU/DE
J800 9736320500-03 JACK SPEAKER CJ-9007-040 Only NC-8911DU/DE
Location Part Code Part Name Remark
J401 F736300011
JACK H/P
EJ-3511
J702 9736330600 JACK USB USB-103 (ANGLE TYPE)
◆◆◆◆◆◆
PCB MAIN ASS'Y
◆◆◆◆◆◆
◆◆◆◆◆◆
PCB FRONT ASS'Y
◆◆◆◆◆◆
Description
Description
◆◆◆◆◆◆
PCB SPEAKER JACK ASS'Y
◆◆◆◆◆◆
◆◆◆◆◆◆
PCB USB&AUX ASS'Y
◆◆◆◆◆◆
Description
Description
NC-8911/NC-8913/NC-8915DU,NC-8911/NC-8913/NC-8915DE SVC BOM
