Daewoo NC-8913 - PCB MP3;CD Assembly Parts; PCB Power Assembly Parts

1
2
3
4
5
6
7
9
9
APPENDIX-ELECTRICALPARTLIST
1
2
3
4
5
6
7
9
9
Location Part Code Part Name Remark
D500
、
D501
、
D502 DIN4001--- DIODE
IN4001
HQ500
TZTA1504S- TR CHIP KTA1504S
HQ508
TZRC107S-- TR CHIP KRC107S
HQ503
、
HQ504
、
HQ509 TZTC3875S- TR CHIP KTC3875Y
IC500
1M5673---- IC M5673 WITHOUT ENCODING MODEL
IC500
1M5675---- IC M5675 WITH ENCODING MODEL
IC501
1EN25F10-- IC FLASH
EN25F10
WITHOUT ENCODING MODEL
IC501
1EN25F20-- IC FLASH
EN25F20
WITH ENCODING MODEL
IC502
1SA5888---
IC MOTOR DRIVER SA5888
IC504
1CW7805--- IC
CW7805
Q500
、
Q507
TZTA1273Y- TR KTA1273Y (A966Y) (KSA928A-Y) (STB1277Y)
Q501
TZS8550Y-- TR S8550
X500
5PQZTT1693 RESONATOR CERA QTTT16.93MMX(3PIN)
Location Part Code Part Name Remark
CC901
CLYL2G472M C LINE ACROSS
DE1307E 472M VA1-KC
（
FORMING
）
FC979
9734600800 HOLDER FUSE CLIP PI5.2 - REEL
FC980
9734600800 HOLDER FUSE CLIP PI5.2 - REEL
FC981
9734600800 HOLDER FUSE CLIP PI5.2 - REEL
FC982
9734600800 HOLDER FUSE CLIP PI5.2 - REEL
F980
5FSGB4012L FUSE GLASS TUBE VDE TL 400MA 250V MF51 NC-8911XDU/DE (230V)
F980
5FSGB6312L FUSE GLASS TUBE VDE MF51 630MA 250V TL NC-8913XDU/DE (230V)
F980
5FSGB8012L FUSE GLASS TUBE VDE TL 800MA 250V MF51 NC-8915XDU/DE (230V)
F981
5FSGB8012L F
USE GLASS TUBE VDE TL 800MA 250V MF51 NC-8911XDU/DE (127V)
F981
5F1GB1222L FUSE GLASS TUBE UL/CSA TL 1.25A 250V MF51 NC-8913XDU/DE (127V)
F981
5F1GB1622L FUSE GLASS TUBE UL/CSA TL 1.6A 250V MF51 NC-8915XDU/DE (127V)
PT903
5TP0066F78 TRANS POWER EI=66X30 127V/230V 60/50Hz NC-8911XDU/DE
PT903
5TP0066F82 TRANS POWER EI=66X35 127V/230V 60/50Hz NC-8913XDU/DE
PT903
5TP0066F84 TRANS POWER EI=66X45 127V/230V 60/50Hz NC-8915XDU/DE
PT
980 5TP8028985 TRANS POWER EI=28X12 230V/50HZ Only PSM MODEL USED
D980
、
D981
、
D982
、
D983
、
D985 DIN4001--- DIODE IN4001 Only PSM MODEL USED
Q981 TZTC3205Y- TR KTC3205Y (KTC2236Y) AUTO Only PSM MODEL USED
R981 RD-4Z100J- R CARBON FILM 1/4 10 OHM J Only PSM MODEL USED
R982 RD-AZ103J- R CARBON FILM 1/6 10K OHM J Only PSM MODEL USED
R983 RD-AZ103J- R CARBON FILM 1/6 10K OHM J Only PSM MODEL USED
RY980 5SC2001A01 SW RELAY SDT-S-105LMR Only PSM MODEL USED
R980
RN-2Y475J- R METAL FILM 1/2 4.7M OHM J
RF982
、
RF983
RF01F4780J-32 R FUSIBLE 1W 0.47 OHM J (32
倍
)
SW901
5S30102377-1 SW VOLTAGE SELE ZH-06-01 OPTION
◆◆◆◆◆◆
PCB POWER ASS'Y
◆◆◆◆◆◆
* END OF REPORT *
Description
Description
◆◆◆◆◆◆
PCB MP3CD ASS'Y
◆◆◆◆◆◆
