ExplodedViewandMechanicalParts List
No. PARTS NAME CODE NO. DESCRIPTIONS Q'TY REMARKS
1 KNOB VR 9CD1369300 HIPS 1
2 DECO CAP 9CD1018400 HIPS 1
3 DECO TUNING 9CD1018500 ABS 1
4 DECO RING 9CD1018600 ABS 1
5 STOPPER 9CD5700700 HIPS 1
6 CUSHION FOOT 9CD4207700 URETHANE D10*4.0T 2
7 WINDOW LCD 9CD1628300 PMMA (SMOG) 1
8 DOOR CD 9CD1819200 HIPS 1
9 PANEL FRONT 9CD0321600 HIPS 1
10 COVER SIDE L 9CD0425400 HIPS 1
11 COVER SIDE R 9CD0425500 HIPS 1
12 GUIDE LCD 9CD2509100 HIPS 1
13 WIDDOW REFLECTOR 9CD162160
0 PMMA (CLEAR) 1
14 SHEET DIFFUSION 9CD9603100 PE 1
15 KNOB POWER 9CD1369500 HIPS 1
16 KNOB OPEN 9CD1369400 HIPS 1
17 PIN GEAR 9CD3501700 PW 1
18 NUT 7391500011 M5X0.8 1
19 GEAR IDLE 9CD2702700 HIPS 1
20 GEAR PVC 9CD2702600 HIPS 1
21 KNOB FUNCTION L 9CD13696L0 HIPS 1
22 KNOB FUNCTION R 9CD13696R0 HIPS 1
23-1 PCB MAIN AS FCDC004810 NC-8915 1
23-2 PCB MAIN AS FCDC004800 NC-8913 1
23-3 PCB MAIN AS FCDC004790 NC-8911 1
24 BRACKET PCB L 9CD2421700 SECC 1.0T 1
25 BRACKET PCB R 9CD2421800 SECC 1.0T 1
26 BRACKET HEAT TR 9
CD2413901 STS 0.4T 2 NC-8911 1pcs
27-1 PCB FUSE AS FCDC005006 NC-8915 1
27-2 PCB FUSE AS FCDC005003 NC-8913 1
27-3 PCB FUSE AS FCDC005000 NC-8911 1
No. PARTS NAME CODE NO. DESCRIPTIONS Q'TY REMARKS
28 PCB FRONT AS FCDC005100 NC-8911/8913/8915 1
29 PCB MP3 CD AS FCDC004900 NC-8911/8913/8915 1
30 BRACKET CD DECK 9CD2421600 HIPS 1
31 CD- PICK UP 9CD6014830 R800 1 PLATE TYPE
32 CD DECK 9CD6016800 8210D 1 ASA
33 COVER TOP 9CD0425200 HIPS 1
34 HOLDER SCREW A 9CD2307500 POM 4
35 HOLDER SCREW B 9CD2307600 POM 4
36-1 HEAT SINK 75 9CD4415300 AL 1 NC-8915 (75W)
36-2 HEAT SINK 50 9CD4415200 AL 1 NC-8913 (50W)
36
-3 HEAT SINK 15 9CD4415000 AL 1 NC-8911 (15W)
37 PLATE MICA 9CD0910600 WHITE MICA 25X30mm 2 NC-8911 1pcs
38 SW VOLTAGE SELE 5S30102377-1 ZH-06-01 1 ONLY FOR TOSHIBA
39 PCB USB&AUX AS FCDC005104 NC-8911/8913/8915 1
40-1 PCB SPEAKER JACK AS FCDC005103 NC-8913/8915 1
40-2 PCB SPEAKER JACK AS FCDC005102 NC-8911 1
41-1 COVER BACK 9CD0425300 HIPS 1 NC-8913/8915
41-2 COVER BACK 9CD0425310 HIPS 1 NC-8911
42 AC CORD F736909021 2X0.75mm2 L=1.85M 1
43 CHASS
IS BOTTOM 9CD0616900 HIPS 1
44 PLATE SENSOR 9CD0916800 PC T=0.5 1
S1 SCREW TAPPTITE 7173301011 TT2 BIN 3X10 MFZN 12
S2 SCREW TAPPTITE 7173301211 TT2 BIN 3X12 BK 23
S3 SCREW TAPPTITE 7173261011 TT2 BIN 2.6X10 MFZN 12
S4 SCREW TAPPTITE 7173401011 TT2 BIN 4.0X10 MFZN 4
S5 SCREW WASHER 9CD3102400 TT2 WAS 3X10+D14 MFZN 3
S6 SCREW TAPPTITE 7173300611 TT2 BIN 3X6 MFZN 9 NC-8911 8pcs
S7 SCREW MACHINE 7003263511 M2.6X3.5 1
S8 SCREW TAPPTITE 7173302111 TT2 BIN 3X21 MFZN 4
