PARTS LIST
DATE:2005-1-25
AM:522-1620KHz
FM:88-108MHZ
Item
Part NO Qty
PROPOSE
Description
Model No:RG-361
REF NO:KW-EP-0171<REV:A0>
99
341-K105MBU-A0 28# 2PIN HSG L=80mm 1 CD DOOR SWITCH
100 343-0070E3U-00
WIRE: UL 28# RED 70MM 1
CASSETTE LED X 1
101 343-0070E2U-00
BLACK 70MM 1
CASSETTE LED X 1
102
343-0150E3U-00 RED 150MM 1
CASSETTE LED X 1
103
343-0150E2U-00 BLACK 150MM 1
CASSETTE LED X 1
104
WIRE: UL 26#
105
343-0050D3U-00 RED 50MM 2 SP“L”x2
106
343-0050D2U-00 BLACK 50MM 2 SP“L”x2
107
343-0120D2U-00 BLACK 120MM 1
WIRE X 1
108
343-0120D8U-00 ORANGE 120MM 1
MOTOR - CD DECK SWITCH X 1
109
343-0170D2U-00 BLACK 170MM 1
MOTOR“-”TO PCB GNDx1
110
343-0170DGU-00 GREEN 170MM 1
MOTOR“+”TO PCB VCCx1
111
343-0250D3U-00 RED 250MM 1 CD DECK SWITCH TO PCB VCC1x1
112
343-0250D2U-00 BLACK 250MM 1 AMP PCB TO VOLx1
113
343-1800D2U-00 BLACK 1800MM 1 FM WIRE x1 COIL: R:3.5T
114
471-0200491-00
SCREW:
PST2x4 1 FRONT PANEL BRACKET x1
115
471-0200621-00 TA/PH 2x6 1 MAGNET HOLDER x1
116
471-0200821-00 TA/PH2x8 1 CD DOOR SWITCH X 1
117
471-0260561-00 MS/PH 2.6x5 1 PVC GEAR X 1
118
471-0261011-00 TA/WH 2.6x10 4 CD DECK X 4
119
471-0180611-00 TA/WH 1.8x6 3 CD DOOR MAGNET HOLDER X 1
120
471-0300821-00 TA/PH 3x8 16
MAIN PCBx7 F.PANELx3 MP3 PCBx4
CASSETTE DOOR LOCK BRACKETx2
121
471-0301011-00 TA/WH 3x10
16
CD DOOR GEAR HOLDERx1 SPx4 AMP.
PCBx2 SPEAKER BOX RUBBER FEETx8
CASSETTE DOOR GEAR HOLDERx1
122
471-0301021-00 TA/PH 3x10 4 CD DECKx4
123
471-0261041-00 TA/kH 2.6x10 2
CD BRACKETx2
124
471-0301221-00 TA/PH 3x12 8
SPEAKER BOX FRONTx8
125
471-0301621-00 TA/PH 3x16 4 BOTTOM CABINET X 8
126
471-0302511-00 TA/WH 3x25 2
TRANSFORMER X 8
127
352-004B201-00
AC SOCKET
1 4B-2
128
251-1830VAB-00 VDE APPROVAL CORD 1
129
PAGE 26 ,TOTAL 31
