CD PLAYING SPECIFICATION
Temp 28
0
C Humidity 85 % DATE: 2005.01.31
A.C 230V 50Hz D.C 12 V
MODEL: RG-361
LOADS 8 ohm Ref.out 50 mW
MEASURING ITEMS CONDITION UNIT NOMINAL LIMIT SAMPLE TEST CONDITION
CD MAX. OUTPUT POWER MW 2500 2300 2500 TCD-782/TCD-784 0dB
CD 10% THD OUTPUT POWER MW 2000 1800 1800 TCD-782/TCD 784 0dB
CD LINE OUT VOLTAGE V -- 0dB 1KHZ TCD-782
MAX. O/P DIS(BASS BOOST .OFF) 1KHZ. 0dB % 23 28 26 TCD-782/TCD 784 0dB
THD AT ReB OUTPUT 1KHZ % 1 -- TCD-782 W/LOW PASS
SEPARATION 1KHZ dB 40 35 40 TCD-782/TCD-784 (SPK O/P)
S/N RATIO 1KHZ dB >50 >50 TCD-782/TCD-784 (SPK O/P)
SCRATCH MM 0.8 0.6 0.8 PHILIPS #5A/444A
INTERRUPTIONS BLACK DOT MM 0.8 0.6 0.8 PHILIPS #5A/444A
FINGER PRINT MM ALL CLEAR ALL PHILIPS #5A/444A
DYNAMIC RANGE dB >45 TCD-782 (SPK O/P)
INITIAL. READING TIME SEC. <8 6 TCD-782
ACCESS TIME
FIRST TRACK SEC. <5 4 TCD-782
LAST TRACK SEC. <14 12
VERTICAL DEVIATION MM 0.8 TCD-732R
HUM & NOISE MIN. VOL. MV <3 1 TCD-782 TNO.8/TCD-784 TNO.7
MAX. VOL MV <10 1.5 BASS BOOST OFF,TONE MAX.
SHOCK ABILITY CENTER qm >100
TENSION GUAGE IMPACT UNIT
TCD-782 TNO.1 & 23 CORNERS qm >100 WITHOUT INTERRUPTION
63HZ dB
127HZ dB +/-3 +1
1KHZ dB 00
6.3KHZ dB
8KHZ dB
10KHZ dB 0 +-3 0
20KHZ dB
REMARK : OTHER SPEC ARE SUBJECT TO CD MECHANISM SPECIFY.
FREQ. RESPONSE
1KHZ=0dB
TCD-782 (SPK O/P)
BASS BOOST OFF
PAGE 3 ,TOTAL 31
