MW RADIO SPECIFICATION
Temp 28
0
C Humidity 85 % DATE: 2005.01.31
A.C 230V 50Hz D.C 12 V
MODEL: RG-361
LOADS 8 ohm Ref.out 50 mW
MEASURING ITEMS CONDITION UNIT NORMAL LIMIT SAMPLE TEST CONDITION
LOW END KHZ 525 +/-5 515
HIGH END KHZ 1630 +/-15 1630
INTERMEDIATE FREQ KHZ 465 +/-3
600KHZ dB 50 58 52
1000KHZ dB 50 58 58
1400KHZ dB 50 58 58
-20dB QUIETING 600KHZ dB 58 64 62
SENSITIVITY 1000KHZ dB 58 64 61
1400KHZ dB 58 64 61
DIAL CALIBRATION ALL POINTS KHZ <30 POINTER WITHIN LETTERING
600KHZ dB 50 40
1000KHZ dB 45 35
1400KHZ dB 45 35
I.F. REJECTION 600KHZ dB 45 40
-6dB BAND WIDTH 1000KHZ KHZ 4-8
ACA +/- 10KHZ 1000KHZ dB 20 15
AGC FIGURE OF MERIT 1000KHZ dB 35 28 100dB/M
RF OVERLOAD DIST. 1000KHZ % 35 100dB/M 60% MOD
10% DIST. O/P POWER 1000KHZ MW 2000 1800 1800
*
1KHZ ; 400HZ
80% MOD.
MAX. O/P POWER 1000KHZ MW 2500 2300 2500
*
1KHZ ; 400HZ
80% MOD.
MAX. O/P. DIS 1000KHZ % 20 25 22
*
1KHZ ; 400HZ
80% MOD.
-6dB AUDIO LOW FREQ HZ 100 150 VOL. AT 75% POSITION
FIDELITY HIGH FREQ HZ 3K 2K2 ADJUST MOD .TO REF
2 IF % <10
3 IF % <10
S/N WITH 74dB/M 1000KHZ dB 35 30 32
DIST. AT Reb O/P 1000KHZ % 355
MODULATION HUM 100dB/
