No. Item Code Description Qty Unit Location
1 003-03906-006 TRANSISTOR 2N3906 TO-92 (PNP
TYPE)
1pc Q1
2 004-35-010 CHOCK COIL 10 UH +/-10%
PK0455S-10uH (V)4x5.6mm
4 pcs L2,L5,L8,L10
3 010-CD192-01M HEATSINK (METAL) CDR192A FOR
M-DRIVER
1 pc 1/FOR U2 D9258 IC
4 012-A1057-006 ELECT. CAP. 1 MFD 50V +/-20% 1
c C25
5 012-A1067-003 ELECT. CAP. 10 MFD 16V +/-20% 6
cs C3,C8,C13,C26,C28,C52
6 012-A1077-003 ELECT. CAP. 100 MFD 16V +/-20%
(5x11)
5 pcs C4,C9,C11,C12,C31
7 012-A2277-002 ELECT. CAP. 220 MFD 10V +/-20%
(6x12)
1 pc C17
8 012-A4757-002 ELECT. CAP. 4.7 MFD 10V +/-20%
(5x11)
1 pc C51
9 012-A4767-002 ELECT. CAP. 47 MFD 10V +/-20% 3
cs C21,C22,C30
10 012-A4777-002 ELECT. CAP. 470 MFD 10V +/-20%
(6x12)
1pc C6
11 021-700 DIODE ZENER 5.1V 1/2W DO-35
BZX55C5V1
1pc D7
12 021-Z0022 DIODE ZENER 2.2V 1
cD4
13 021-Z0027 DIODE ZENER 2.7V 0.5W 1
cD2
14 024-16.934MHz RESONATOR CERAMIC 16.934MHZ
2PIN
1pc Y1
15 046-02S-P2 Connector 2 Pin Socket (Pitch=2mm) 1
cJ6
16 046-03S-E Connector 3 Pin Socket (E-TYPE)
P=2.5MM TJC3-nA
1pc J2
17 046-03S-P2 Connector 3 Pin Socket (Pitch=2mm) 1
cJ8
18 046-04S-P2 Connector 4 Pin Socket (Pitch=2mm) 1
cJ3
19 046-06S-P2 Connector 6 Pin Socket (Pitch=2mm) 3
cs J1,J7,J9
20 046-16SH-P1 Connector 16 Pin Socket (P=1mm) 1.0-
2C- 16WS (Black)
1 pc CDM200
22
DAT HK Limited
TP-501G Part List
Description : 全球線路 CD MPEG+MP3+WMA (NOR) DA11V Verified Date : 01/18/2006
Model No : TP-501G
Part No : BCM138AR-A501 Status : MP(量產)
