Daewoo TP-501G - Page 25

DAT HK Limited
TP-501G Part List
No. Item Code Description Qty Unit Location
1 001-UTM1800A-0MP P.C.B UTM1800A CD/MP3/WMA
MPEG GSL88303 D-SIDE BOARD
1pc
2 002-00324-S15 I.C. LM324SO SOP-14 20V 1
p
cU7
3 002-02752-000 I.C. CE2752 SOIC-14 STEREO AUDIO
DAC
1pc U1
4 002-09258-053 I.C. D9258 4-CH MOTOR DRIVER 1
p
cU2
5 002-37020-0C5 I.C. SST37VF020-70-3G-NH PLCC 1
p
c U10
6 002-51181-064 I.C. HY5118154B 1
p
cU5
7 002-74H04-200 I.C. 74HCU04D |PHILIPS| 2
p
cs U3,4
8 002-88303-070 I.C. GSL88303 MP3/WMA DSP (XIN) 1
p
cU8
9 003-00114-135 CHIP TRANSISTOR DTC114TE 4
p
cs Q4,6,7,8
10 003-00114-T36 CHIP TRANSISTOR DTA114TKA
PNP SC-59
7 pcs Q2,5,10,11,12,13,14
11 003-08050-000 CHIP TRANSISTOR MMT8050 SOT-
23 NPN
1pc Q3
12 003-08550-054 CHIP TRANSISTOR MMT8550C SOT-
23 PNP
1pc Q9
13 005-O000B-027 CHIP RESISTOR 0 OHM (0805) +/-5% 1
p
c U11
14 005-S000B-013 CHIP RESISTOR 0 OHM (0603) +/-5%
1/16W
12 pcs L1,L4,L6,L7,L9,L14,L15,L
200,L201,L202,L203 R122
15 005-S100B-013 CHIP RESISTOR 10 OHM (0603) +/-
5% 1/16W
3 pcs R43,62,200
16 005-S101B-013 CHIP RESISTOR 100 OHM (0603) +/-
5% 1/16W
14 pcs R14,R24,R35,R49,R64,R11
2,R113,R114,R115,R128,R
206,R214,R215,R216
17 005-S102B-013 CHIP RESISTOR 1 K (0603) +/-5%
1/16W
21 pcs R2,R3,R4,R5,R6,R7,R8,R1
3,R38,R51,R89,R90,R130,
R131,R132,R133,R134,R1
35,R218,R219,R220
18 005-S103B-013 CHIP RESISTOR 10 K (0603) +/-5%
1/16W
22 pcs R12,R15,R21,R22,R26,R33
,R34,R36,R40,R42,R46,R4
7,R48,R60,R66,R78,R92,R
108,R109,R111,R136,R217
19 005-S104B-013 CHIP RESISTOR 100K (0603) +/-5%
1/16W
11 pcs R9,16,29,32,44,68,70,74,75
,80,81
20 005-S152B-013 CHIP RESISTOR 1.5K (0603) +/-5%
1/16W
3 pcs R85,211,212
21 005-S153B-013 CHIP RESISTOR 15K (0603) +/-5%
1/16W
5 pcs R50,52,63,65,69
22 005-S154B-013 CHIP RESISTOR 150K (0603) +/-5%
1/16W
1 pc R213
23
Description : 全球線路 CD MPEG+MP3+WMA (SMT) DA11V Verified Date : 01/18/2006
Model No : TP-501G Page : 1
Part No : BCM138AR-A502 Status : MP(量產)
