TP-501G Part List
No. Item Code Description Qty Unit Location
23 005-S182B-013 CHIP RESISTOR 1.8K (0603) +/-5%
1/16W
1 pc R204
24 005-S220B-013 CHIP RESISTOR 22 OHM (0603) +/-
5% 1/16W
3 pcs R101,102,103
25 005-S222B-013 CHIP RESISTOR 2.2K (0603) +/-5%
1/16W
1 pc R37
26 005-S223B-013 CHIP RESISTOR 22K (0603) +/-5%
1/16W
1 pc R45
27 005-S273B-013 CHIP RESISTOR 27K (0603) +/-5%
1/16W
3 pcs R30,R87,R88
28 005-S332B-013 CHIP RESISTOR 3.3K (0603) +/-5%
1/16W
6 pcs R28,57,58,59,72,73
29 005-S333B-013 CHIP RESISTOR 33K (0603) +/-5%
1/16W
7 pcs R23,25,67,207,208,209,210
30 005-S391B-013 CHIP RESISTOR 390 OHM (0603) +/-
5% 1/16W
1 pc R10
31 005-S392B-013 CHIP RESISTOR 3.9 K (0603) +/-5%
1/16W
7 pcs R77,79,84,94,97,98,99
32 005-S472B-013 CHIP RESISTOR 4.7K (0603) +/-5%
1/16W
9 pcs R11,R20,R39,R71,R76,R82
,R83,R106,R110
33 005-S473B-013 CHIP RESISTOR 47K (0603) +/-5%
1/16W
1 pc R86
34 005-S562B-013 CHIP RESISTOR 5.6K (0603) +/-5%
1/16W
3 pcs R18,19,27
35 005-S682B-013 CHIP RESISTOR 6.8K (0603) +/-5% 2
p
cs R53,54
36 005-S752B-013 CHIP RESISTOR 7.5K (0603) +/-5%
1/16W
4 pcs R91,R95 R100,105
37 005-S820B-013 CHIP RESISTOR 82 OHM (0603) +/-
5% 1/16W
1 pc R17
38 005-S821B-013 CHIP RESISTOR 820 OHM (0603) +/-
5% 1/16W
1 pc R41
39 005-S822B-013 CHIP RESISTOR 8.2K (0603) +/-5%
1/16W
3 pcs R31,55,56
40 016-S0501-006 CHIP CAPACITOR 5 PF 50V (0603)
+/-0.25PF NPO
1 pc C36
41 016-S1005-006 CHIP CAPACITOR 10 PF 50V (0603)
+/-0.25PF NPO
1 pc C43
