TP-501G Part List
No. Item Code Description Qty Unit Location
42 016-S1015-006 CHIP CAPACITOR 100 PF 50V (0603)
+/-5% NPO
1 pc C53
43 016-S1026-006 CHIP CAPACITOR 0.001UF 50V
(0603) +/-10%
4 pcs C40,44,46,48
44 016-S1036-006 CHIP CAPACITOR 0.01UF 50V (0603)
+/-10%
7 pcs C14,32,39,202,223,224,225
45 016-S1046-004 CHIP CAPACITOR 0.1 UF 25V (0603)
+/-10%
34 pcs C1,C15,C16,C18,C19,C27,
C33,C35,C38,C50,C54,C55
,C57,C58,C61,C62,C63,C2
00,C201,C203,C205,C207,
C208,C209,C210,C211,C2
12,C213,C214,C217,C219,
C220,C221,C222
46 016-S1205-006 CHIP CAPACITOR 12 PF 50V (0603)
+/-5%
1 pc C216
47 016-S2205-006 CHIP CAPACITOR 22 PF 50V (0603)
+/-5%
1 pc C218
48 016-S2226-006 CHIP CAPACITOR 0.0022UF 50V
(0603) +/-10% X7R
7 pcs C5,10,41,42,45,47,59
49 016-S3005-006 CHIP CAPACITOR 30 PF 50V (0603)
+/-5% NP
2 pcs C20,37
50 016-S3916-006 CHIP CAPACITOR 390 PF (0603) +/- 1
p
c C23
51 016-S3926-006 CHIP CAPACITOR 0.0039 UF (0603)
+/-10% 5
2 pcs C49,60
52 016-S4726-006 CHIP CAPACITOR 0.0047UF 50V
(0603) +/-10
1 pc C29
53 016-S4746-002 CHIP CAPACITOR 0.47 UF 10V
(0603) +/-10%
4 pcs C34,56,204,206
54 016-S6826-006 CHIP CAPACITOR 6800 PF 50V
(0603) +/-10%
2 pcs C2,7
55 021-005-S DIODE LL4148 (SMT) 3
p
cs D1,3,5
56 021-DAP222 SMT SWITCHING DIODE ARRAYS
DAP222
1pc D6
Description : 全球線路 CD MPEG+MP3+WMA (SMT) DA11V Verified Date : 01/18/2006
25
Model No : TP-501G Page : 1
Part No : BCM138AR-A502 Status : MP(量產)
