TP-501G Part List
No. Item Code Description Qty Unit Location
1 003-08050-014 TRANSISTOR S8050 TO-92 1
p
cQ1
2 006-BCM138A-01 LCD DISPLAY 48X23X2MM 1
p
c
3 009-26-018-P1 HEATSEAL CONNECTOR 26 PIN x
18MM PITCH=1MM
1 pc 1/LCD-LCD PCB
4 012-C1067-002 ELECT. CAP. MINI 10 MFD 10V +/-
20% (4x7)
2 pcs C3,4
5 021-005 DIODE IN4148 1
p
cD4
6 021-200 DIODE ZENER 4.7V 0.5W 1
p
cD6
7 022-003O Led Lamp 2x3mm FT-384SOC-Y 1 pc
(1/背光燈 D2)
8 036-00CD3-UL06W2-
P2
6 PIN WIRE 350MMx6 UL2651
28AWG P=2MM Hx1 CD3
1 pc 1/LCD DISPALY PCB
CN4-MPEG PCB J7
9 053-CDM303A-01 FILTER PLATE CDM303A-206 1 pc
1/濾光紙
10 054-CDM303A-01 REFLECT PLATE 63.0x19.8x0.2MM
CDM303A-205
1pc
1/反光片
11 077-CDM303A-01 SILVER PLATE 148x3MM CDM303A-
204
1pc
1/錫鉑紙
12 077-DH801-02 SILVER PLATE (B) DH801-209 1 pc
1/反光紙
13 078-BCX125B-02 LCD BRACKET BCX125B-202 1
p
c
No. Item Code Description Qty Unit Location
1 001-BCM138A-0GN P.C.B BCM138A LCD DISPLAY
GSL88303 S-SIDE REV-0
1pc
2 003-08050-000 CHIP TRANSISTOR MMT8050 SOT-
23 NPN
1pc Q2
3 005-S020B-013 CHIP RESISTOR 2 OHM (0603) +/-5%
1/16W
2 pcs J1,4
4 005-S101B-013 CHIP RESISTOR 100 OHM (0603) +/-
5% 1/16W
4 pcs R4,6,8,9
5 005-S102B-013 CHIP RESISTOR 1 K (0603) +/-5% 2
p
cs R5,R7
6 005-S123B-013 CHIP RESISTOR 12K (0603) +/-5%
1/16W
1pc R1
7 005-S222B-013 CHIP RESISTOR 2.2K (0603) +/-5%
1/16W
1pc R2
8 005-S272B-013 CHIP RESISTOR 2.7K (0603) +/-5%
1/16W
1pc R3
9 016-S1046-004 CHIP CAPACITOR 0.1 UF 25V (0603)
+/-10%
2 pcs C6,102
26
Description : LCD (NOR) BOARD HT1621 IC Verified Date : 01/18/2006
Model No : TP-501G Page : 1
Part No : BCM138AR-A201 Status : MP(量產)
Description : LCD (SMT) BOARD HT1621 IC Verified Date : 01/18/2006
Model No : TP-501G Page : 1
Part No : BCM138AR-A202 Status : MP(量產)
