TP-501G Part List
No. Item Code Description Qty Unit Location
1 002-01621-000 I.C. ET1621 DIE LCD DRIVER 1
p
c
No. Item Code Description Qty Unit Location
1 002-02003-G53 I.C. CD2003GP AM/FM RADIO 1
p
c IC8
2 002-08854-030 I.C. CSC8854 1
p
c IC2
3 004-3-1000 CHOCK COIL 10 MH +/-10%
(4.5x6mm) (V)
2 pcs L8,9
4 007-101083A4 I.F.T. 10MM 1083A4 (Red) 1
p
cT1
5 007-101083B I.F.T. 10MM 1083B (Yellow) 1
p
c
6 011-A0308-020 CERAMIC CAP. 3 PF 63V +/-20/50% 1
p
c C99
7 012-A1057-006 ELECT. CAP. 1 MFD 50V +/-20% 5
p
cs C13,14,21,22,25
8 012-A1067-003 ELECT. CAP. 10 MFD 16V +/-20% 2
p
cs C27,57
9 012-A1077-002 ELECT. CAP. 100 MFD 10V +/-20%
(5x11)
1 pc C96
10 012-A1087-004 ELECT. CAP. 1000 MFD 25V +/-20%
(10x18)
1 pc C506
11 012-A2277-002 ELECT. CAP. 220 MFD 10V +/-20%
(6x12)
2 pcs C69,81
12 012-A3357-003 ELECT. CAP. 3.3 MFD 16V +/-20%
(5x11)
2 pcs C9,94
13 012-A4747-006 ELECT. CAP. 0.47 MFD 50V +/-20%
(5x11)
1 pc C26
14 013-A1026-000 MYLAR CAP. 0.001 UF +/-10% 1
p
c C82
15 017-51355 Ferrite Bar 5x13x55mm 1
p
c
16 018-05-02 BAR HOLDER 5MM (5X12.5) 2
p
cs
17 019-01R CERAMIC FILTER LT10.7MA5A
(RED) 10.7MA5A 3 PIN
1 pc CF2
18 019-10.7M-03 CERAMIC FILTER JT10.7MG3A
(RED) 2 PIN
1 pc CF4
19 019-20 CERAMIC FILTER SFU465B 1
p
c CF1
20 021-005 DIODE IN4148 2
p
cs D6,7
21 021-2638 DIODE AFC/SEL IS2638 1
p
cD8
22 021-5391 DIODE IN5391 DO-15 4
p
cs D501,502,503,504
23 021-700 DIODE ZENER 5.1V 1/2W DO-35
BZX55C5V1
1 pc ZD1
27
Description : LCD (BONDING) BOARD HT1621 IC Verified Date : 01/18/2006
Model No : TP-501G Page : 1
Part No : BCM138AR-A203 Status : MP(量產)
Description : AF-S (NOR) BOARD CD2003GP IC Verified Date : 01/18/2006
Model No : TP-501G Page : 1
Part No : BCM138AR-A001 Status : MP(量產)
