DAT HK Limited
TP-501G Part List
No. Item Code Description Qty Unit Location
24 023-00231-105W P.V.C. AM/FM CBM-443DF-1DF
SHINTO 120-220gf.cm (W05)
1pc
25 025-005K3 SEMI FIXED 5K OHM 3 PIN +,-20% 1
c VR1
26 029-1243 SLIDE SWITCH SS-43D07LT-01 1
c SW3
27 033-125-20-120 AM COIL 125:20 (0.10x1) L=120MM
@11MM
1pc
28 035-4545-01 FM Coil 4.5mm x 4 1/2T 1
cL7
29 035-5025-01 FM Coil 5mm x 2 1/2T 1
cL4
30 035-5035-01 FM Coil 5mm x 3 1/2T 1
cL2
31 046-02S-P2 Connector 2 Pin Socket (Pitch=2mm) 1
c CN1
32 046-04S-P2 Connector 4 Pin Socket (Pitch=2mm) 1
c CN10
33 051-NPO020 CERAMIC NPO CAP. 20 PF +/-0.5% 1
c C99
34 051-NPO025 CERAMIC NPO CAP. 25 PF +/-0.5% 1
c C98
35 051-NPO150 CERAMIC NPO CAP. 150 PF +/-0.5% 1
c C77
No. Item Code Description Qty Unit Location
1 001-BCM138A-001 P.C.B BCM138A AM/FM+AC+VOL S-
SIDE BOARD REV-0
1pc
2 005-B000B-027 CHIP RESISTOR 0 ohm (1206) +/-5% 1
c J51
3 005-S000B-013 CHIP RESISTOR 0 OHM (0603) +/-5%
1/16W
5 pcs R1,R52,R92,R646,R648
4 005-S102B-013 CHIP RESISTOR 1 K (0603) +/-5% 2
cs R6,40
5 005-S103B-013 CHIP RESISTOR 10 K (0603) +/-5%
1/16W
3 pcs R26,34,35
6 005-S104B-013 CHIP RESISTOR 100K (0603) +/-5%
1/16W
2 pcs R25,39
7 005-S224B-013 CHIP RESISTOR 220K (0603) +/-5%
1/16W
3 pcs R37,645
8 005-S22XB-013 CHIP RESISTOR 2.2 OHM (0603) +/-
5% 1/16W
1 pc R42
9 005-S332B-013 CHIP RESISTOR 3.3K (0603) +/-5%
1/16W
3 pcs R33,R36,R339
10 005-S470B-013 CHIP RESISTOR 47 OHM (0603) +/-
5% 1/16W
1 pc R43
Model No : TP-501G Page : 1
Part No : BCM138AR-A001 Status : MP(量產)
Description : AF-S (NOR) BOARD CD2003GP IC Verified Date : 01/18/2006
28
Description : AF-S (SMT) BOARD CD2003GP IC Verified Date : 01/18/2006
Model No : TP-501G Page : 1
Part No : BCM138AR-A002 Status : MP(量產)
To Next Page
