TP-501G Part List
No. Item Code Description Qty Unit Location
11 005-S680B-013 CHIP RESISTOR 68 OHM (0603) +/-
5% 1/16W
1 pc R53
12 005-S681B-013 CHIP RESISTOR 680 OHM (0603) +/-
5% 1/16W
1 pc R41
13 016-S0401-006 CHIP CAPACITOR 4 PF 50V (0603)
+/-0.25PF NPO
1 pc C23
14 016-S1026-006 CHIP CAPACITOR 0.001UF 50V
(0603) +/-10%
1 pc C114
15 016-S1036-006 CHIP CAPACITOR 0.01UF 50V (0603)
+/-10%
3 pcs C18,20,70
16 016-S1046-004 CHIP CAPACITOR 0.1 UF 25V (0603)
+/-10%
8 pcs C17,C33,C46,C63,C65,C67
,C80,C101
17 016-S2236-006 CHIP CAPACITOR 0.022 UF (0603)
+/-10%
4 pcs C501,C502,C503,C504
18 016-S2705-006 CHIP CAPACITOR 27 PF 50V (0603)
+/-5%
1 pc C10
19 016-S3005-006 CHIP CAPACITOR 30 PF 50V (0603)
+/-5% NP
3 pcs C32,106,107
20 016-S5626-006 CHIP CAPACITOR 0.0056 UF 50V
(0603) +/-1
2 pcs C110,112
No. Item Code Description Qty Unit Location
1 001-BCM138A-0KN P.C.B BCM138A KEY GSL88303 S-
SIDE BOARD REV-0
1pc
2 012-C1067-003 ELECT. CAP. MINI 10 MFD 16V +/-
20% (4x7) -50:c/+105:c (M)
1pc C7
3 022-002GL Led Lamp 3mm (Green) L=28m
m
1
p
c 1/ST LED
4 022-002RL Led Lamp 3mm (Red) L=28m
m
1
p
c 1/POWER LED
5 024-TSOP18 INFRARED RECEIVR MODULE 1 pc
遙控接收頭
6 029-0166 BAND SWITCH PBS-2201 1
p
c
7 029-0621 TACT SWITCH TS-00104 A 7
p
cs
8 036-0036-UL02W1-P2 2 Pin Wire 200mmx2 UL1007#26 (Hx1)
P=2MM CD36
1 pc 1/KEY PCB CN1-RADIO
PCB CN1 FOR FM ST
9 036-CD102-UL03W-
P2
3 PIN WIRE 250MMx3 UL2651
28AWG (Hx1) P=2MM CD102A
1 pc 1/KEY PCB-MPEG PCB
J8
10 036-DVD508-UL04W 4 PIN WIRE 250MM*4 UL2651#28
(H*0) DVD508
1 pc 1/KEY PCB J2-J3
11 036-HT651-UL06W1-
P2
6 PIN WIRE 170MM*6 UL2651#26
(Hx1) P=2MMHTR651
1 pc 1/KEY PCB CN2-MPEG
PCB J9
Model No : TP-501G Page : 1
Part No : BCM138AR-A002 Status : MP(量產)
Description : AF-S (SMT) BOARD CD2003GP IC Verified Date : 01/18/2006
29
Description : KEY BOARD Verified Date : 01/18/2006
Model No : TP-501G Page : 1
Part No : BCM138AR-A204 Status : MP(量產)
