TP-501G Part List
No. Item Code Description Qty Unit Location
1 002-03220-H12 I.C. HWCAT LA3220 2 CH
EQUALIZER AMP
1 pc U201
2 005-C151B-023 RESISTOR 150 OHM 1/4W +/-5% 1
p
c R225
3 005-C390B-023 RESISTOR 39 OHM 1/4W +/-5% 2
p
cs R207,208
4 011-A1028-020 CERAMIC CAP. 0.001 UF 63V +/- 2
p
cs C218,219
5 011-A1048-010 CERAMIC CAP. 0.1 UF 63V +/- 1
p
c C222
6 011-A2008-020 CERAMIC CAP. 20 PF 63V +/- 2
p
cs C210,211
7 011-A2238-030 CERAMIC CAP. 0.022 UF 63V +/- 1
p
c C221
8 012-A1067-002 ELECT. CAP. 10 MFD 10V +/-20%
5x11mm
2 pcs C212,213
9 012-A2267-002 ELECT. CAP. 22 MFD 10V +/-20% 2
p
cs C206,207
10 012-A2277-002 ELECT. CAP. 220 MFD 10V +/-20%
(6x12)
2 pcs C201,220
11 012-A3347-006 ELECT. CAP. 0.33 MFD 50V +/-20%
(5x11)
2 pcs C239,240
12 012-A3357-006 ELECT. CAP. 3.3 MFD 50V +/-20%
(5x11)
2 pcs C227,238
13 012-A4757-002 ELECT. CAP. 4.7 MFD 10V +/-20%
(5x11)
4 pcs C204,205,214,215
14 012-A4767-002 ELECT. CAP. 47 MFD 10V +/-20% 3
p
cs C223,224,225
15 013-A2226-000 MYLAR CAP. 0.0022 UF +/-10% 2
p
cs C216,217
16 013-A2236-000 MYLAR CAP. 0.022 UF +/-10% 2
p
cs C208,209
17 013-A2726-000 MYLAR CAP. 0.0027 UF +/-10% 2
p
cs C202,203
18 021-005 DIODE IN4148 4
p
cs D202,D203,D204,D205
19 021-300 DIODE ZENER 6.8V 1
p
cD1
20 029-0304 PUSH SWITCH PS922 1
p
c SW201
21 036-CD210-UL07W-
P2
7 PIN WIRE 220MMx7 UL2651#28
(Hx1) P=2MMCD210
1 pc 1/REC PCB CON3-
POWER PCB CON11
22 046-03S-E Connector 3 Pin Socket (E-TYPE)
P=2.5MM TJC3-nA
1 pc CN404
23 060-001 Condenser Mic -60+/-2Db @9.7mm. 1
p
c
24 084-UL150 Shield Wire 150mm (Single) UL1533
28AWG
1 pc 1/REC PCB-MIC
30
Description : RECORDING (NOR) BOARD ST Verified Date : 01/18/2006
Model No : TP-501G Page : 1
Part No : BCM138AR-A301 Status : MP(量產)
