DAT HK Limited
TP-501G Part List
No. Item Code Description Qty Unit Location
28 081-PM 23TAPTITE Screw P2x3M (Taptite) 1 pc
1/卡式機芯與錄音鐵片
29 081-PM 265 Screw P2.6x5M 1 pc
1/PVC與調諧鈕軸
30 081-PM 38 Screw P3x8Mx0.5 1 pc
1/天線與頂殼
31 081-WA 310 Screw W3x10A 8 pcs
1/卡式阻尼輪 2/喇叭碼與
面殼 3/回音筒與面殼 2/打
機板用
32 081-WA 312 Screw W3x12A 2 pcs
2/AC插與底殼
33 081-WA 316 Screw W3x16A 2 pcs
2/火牛與底殼
34 083-120G Jumper Wire (8x1.2) 120mm Green 2 pcs 1/POWER PCB R-CH-SPK
(+) 1/BATT (+)-AC
35 083-150 Jumper Wire (8x1.2) 150mm 1
c 1/FM ANT
36 083-150BK Jumper Wire (8x1.2) 150mm Black 1
c 1/BATT (-)-AC PCB GND
37 083-150R Jumper Wire (8x1.2) 150mm Red 1 pc 1/AC SOCKET-AC PCB
VCC
38 083-250BK Jumper Wire (8x1.2) 250mm Black 1 pc
1/焊AV PCB VCC-LCD
PCB AC
39 083-300BK Jumper Wire (8x1.2) 300mm Black 2 pcs 1/POWER PCB GND -
SPK(-) 1/AC PCB VCC-
LCD PCB AC
40 083-300G Jumper Wire (8x1.2) 300mm Green 2
cs MAIN PCB SPL - L
41 083-80BK Jumper Wire (8x1.2) 80mm Black 1 pc 1/POWER PCB R-CH-SPK
(-)
42 087-BCB138A-01 CASSETT DOOR SPRING BCB138A- 1
c
43 087-CD210-03 BATTERY SPRING |-| CD210-204 4
cs
No. Item Code Description Qty Unit Location
1 002-01117-067 I.C. UTC LD1117/A -3.3 TO-220 1
c Q18
2 002-08227-037 I.C. D8227 1
c IC2
3 003-00882-004 TRANSISTOR 2SD882/3DA882/HS882
(NPN) TO-126
1 pc Q14
4 005-C100B-023 RESISTOR 10 OHM 1/4W +/-5% 1
c R261
5 005-C101B-023 RESISTOR 100 OHM 1/4W +/-5% 1
c R293
6 005-C151B-013 RESISTOR 150 OHM 1/16W +/-5% 2
cs R5,R10
7 005-C151B-023 RESISTOR 150 OHM 1/4W +/-5% 2
cs R22,R272
8 005-C221B-023 RESISTOR 220 OHM 1/4W +/-5% 1
c R230
Model No : TP-501G Page : 1
Part No : BCM138A-B004 Status : MP(量產)
Description : MECHANISM 120V ST (全球線路) METAL GRILL Verified Date : 01/18/2006
34
Description : POWER (NOR) BOARD ST (DAEWOO-1客戶 普通) Verified Date : 01/18/2006
Model No : TP-501G Page : 1
Part No : BCW138AR-A101 Status : MP(量產)
To Next Page
