DAT HK Limited
TP-501G Part List
No. Item Code Description Qty Unit Location
9 005-C22XB-013 RESISTOR 2.2 OHM 1/16W +/-5% 2
p
cs R212,R213
10 010-CD190-02 HEATSINK CDR190B-204 1
p
c 1/FOR Q14 D882
11 010-CD60-04 Heatsink FOR 7808 CD60 2 pcs 1/FOR Q14 D882 1/FOR
CD117A
12 012-A1057-006 ELECT. CAP. 1 MFD 50V +/-20%
(5x11)
9 pcs C2,C4,C6,C99,C102,C103,
C214,C286,C288
13 012-A1067-002 ELECT. CAP. 10 MFD 10V +/-20%
5x11mm
1 pc C234
14 012-A1077-002 ELECT. CAP. 100 MFD 10V +/-20%
(5x11)
2 pcs C210,C212
15 012-A1077-003 ELECT. CAP. 100 MFD 16V +/-20%
(5x11)
1 pc C297
16 012-A2247-003 ELECT. CAP. 0.22 MFD 16V +/-20%
(5x11)
2 pcs C85,C86
17 012-A2277-003 ELECT. CAP. 220 MFD 16V +/-20%
(6x12)
3 pcs C203,C219,C296
18 012-A2277-004 ELECT. CAP. 220 MFD 25V +/-20%
(8x12)
1 pc C284
19 012-A2287-004 ELECT. CAP. 2200 MFD 25V +/-20%
(13x25)
1 pc C200
20 012-A4777-002 ELECT. CAP. 470 MFD 10V +/-20%
(6x12)
5 pcs C101,C202,C205,C206,C2
85
21 012-A4777-003 ELECT. CAP. 470 MFD 16V +/-20%
(8x12)
1 pc C299
22 012-C1057-006 ELECT. CAP. MINI 1 MFD 50V +/-
20% (4x7)
1 pc C213
23 012-C2257-006 ELECT. CAP. MINI 2.2 MFD 50V +/-
20% 4x7m
1 pc C221
24 012-G1078-002 TAIWAN ELECT CAP. 100 MFD 10V
(5x7)
3 pcs C209,C211,C291
25 021-005 DIODE IN4148 1
p
c D14
26 021-010-2 DIODE IN4001 COSMOS 3
p
cs D15,D17,D18
27 021-5818 DIODE IN5818 DO-41 1
p
c D16
28 021-Z0036 DIODE ZENER 3.6V 0.5W 1
p
c ZD1
29 021-Z0075 DIODE ZENER 7.5V 1
p
c D13
30 027-V16LG3N(PH)-B VOLUME 16MM B50K X2 W/O
SWITCH L=20MM
1pc
31 029-1243 SLIDE SWITCH SS-43D07LT-01 1
p
c SW1
32 030-1027P 3.5MM STEREO 3 PIN+2X2JACK ST-
203-003AD PLASTIC
1pc
Model No : TP-501G Page : 1
Part No : BCW138AR-A101 Status : MP(量產)
Description : POWER (NOR) BOARD ST (DAEWOO-1客戶 普通) Verified Date : 01/18/2006
