TP-501G Part List
No. Item Code Description Qty Unit Location
33 036-BB137-UL02W-
P2
2 PIN WIRE 180MMx2 UL1007#26
(Hx1) P=2MM BBX137A
1 pc 1/POWER PCB CON34-
KEY PCB CN3
34 036-CD116-UL04W-
P2
4 PIN WIRE 200MMx4 UL2651#28
Hx1 P=2MM CD116
1 pc 1/POWER PCB CON6-
RADIO PCB CON2
35 036-CD128-UL04AW-
P2
4 PIN WIRE 130MM*4
UL2547/1007#26 (H*1) PITCH=2MM
1 pc 1/POWER PCB CON4-
MPEG PCB J3
36 036-CD210-UL05W-
P2
5 PIN WIRE 160MMx5 UL2651#28
(Hx1) P=2MMCD210
1 pc 1/POWER PCB CON21-
PHONES PCB
37 036-CD48-UL03W2 3 Pin Wire 120mmx3 UL1007 26AWG
(Hx1) CD48C
1 pc 1/POWER PCB CON33-
MPEG PCB J2
38 036-DVD921-UL05W-
P2
5 PIN WIRE 150MMx5 UL2651#28
(Hx1) P=2MMDVD921
1 pc 1/POWER PCB CON20-
VOL PCB
39 036-HT651-UL02W-
P2
2 PIN WIRE 250MM*2 UL1007#26
(Hx1) P=2MMHTR651
1 pc 1/POWER PCB CON9-
REMOTE PCB
40 046-02S-P2 Connector 2 Pin Socket (Pitch=2mm) 2
cs CON9,CON34
41 046-04S-P2 Connector 4 Pin Socket (Pitch=2mm) 1
c CON11
42 046-05S-P2 Connector 5 Pin Socket (Pitch=2mm) 2
cs CON20,CON21
43 046-07S-P2 Connector 7 Pin Socket (Pitch=2mm) 1
c CON5
44 079-174 Eyelet 1.7x4mm 9 pcs VCC,GND,R-CH,L-
CH,GND2,VCC,GND,AC1
,AC2
45 081-PM 38 Screw P3x8Mx0.5 1
c 1/FOR Q14 D882
46 081-PT 36 Screw P3x6T 1
c 1/FOR Q18 UTC1117
No. Item Code Description Qty Unit Location
1 001-BCM138A-0N6 P.C.B BCM138A POWER+VOL+PH S-
SIDE BOARD REV-0
1pc
2 003-09014-022 CHIP TRANSISTOR S9014C (SOT-23) 7
cs Q1,Q2,Q8,Q9,Q11,Q12,Q1
3 005-B000B-027 CHIP RESISTOR 0 ohm (1206) +/-5% 3
cs J2,J5,J6
4 005-S000B-013 CHIP RESISTOR 0 OHM (0603) +/-5%
1/16W
2 pcs R307,R308
5 005-S102B-013 CHIP RESISTOR 1 K (0603) +/-5%
1/16W
7 pcs R10,R13,R217,R218,R219,
R220,C275
6 005-S103B-013 CHIP RESISTOR 10 K (0603) +/-5%
1/16W
3 pcs R301,R302,R314
Model No : TP-501G Page : 1
Part No : BCW138AR-A101 Status : MP(量產)
Description : POWER (NOR) BOARD ST (DAEWOO-1客戶 普通) Verified Date : 01/18/2006
36
Description : POWER (SMT) BOARD ST (DAEWOO-1客戶) Verified Date : 01/18/2006
Model No : TP-501G Page : 1
Part No : BCW138AR-A103 Status : MP(量產)
To Next Page
