TP-501G Part List
No. Item Code Description Qty Unit Location
7 005-S104B-013 CHIP RESISTOR 100K (0603) +/-5%
1/16W
1 pc R259
8 005-S222B-013 CHIP RESISTOR 2.2K (0603) +/-5%
1/16W
2 pcs R14,R287
9 005-S223B-013 CHIP RESISTOR 22K (0603) +/-5%
1/16W
2 pcs R5,R294
10 005-S272B-013 CHIP RESISTOR 2.7K (0603) +/-5%
1/16W
2 pcs R202,R313
11 005-S273B-013 CHIP RESISTOR 27K (0603) +/-5%
1/16W
2 pcs R70,R71
12 005-S332B-013 CHIP RESISTOR 3.3K (0603) +/-5%
1/16W
9 pcs R1,R4,R7,R9,R11,R283,R2
84,R292,R312
13 005-S392B-013 CHIP RESISTOR 3.9 K (0603) +/-5%
1/16W
4 pcs R8,R12,R59,R60
14 005-S471B-013 CHIP RESISTOR 470 OHM (0603) +/-
5% 1/16W
2 pcs R6,R295
15 005-S473B-013 CHIP RESISTOR 47K (0603) +/-5%
1/16W
2 pcs R205,R206
16 005-S561B-013 CHIP RESISTOR 560 OHM (0603) +/-
5% 1/16W
2 pcs R214,R215
17 005-S564B-013 CHIP RESISTOR 560K (0603) +/-5%
1/16W
2 pcs R2,R290
18 005-S681B-013 CHIP RESISTOR 680 OHM (0603) +/-
5% 1/16W
1 pc R296
19 005-S822B-013 CHIP RESISTOR 8.2K (0603) +/-5%
1/16W
4 pcs R3,R291,R305,R306
20 016-S1015-006 CHIP CAPACITOR 100 PF 50V (0603)
+/-5% NPO
2 pcs C3,C287
21 016-S1026-006 CHIP CAPACITOR 0.001UF 50V
(0603) +/-10%
2 pcs C215,C216
22 016-S1046-004 CHIP CAPACITOR 0.1 UF 25V (0603)
+/-10%
9 pcs C207,C208,C233,C241,C2
80,C290,C292,C293,C298
23 016-S6826-006 CHIP CAPACITOR 6800 PF 50V
(0603) +/-10%
2 pcs C282,C283
24 016-S6837-006 CHIP CAPACITOR 0.068UF 50V
(0603) +/-20%
2 pcs C1,C5
Model No : TP-501G Page : 1
Part No : BCW138AR-A103 Status : MP(量產)
Description : POWER (SMT) BOARD ST (DAEWOO-1客戶) Verified Date : 01/18/2006
