TP-501G Part List
No. Item Code Description Qty Unit Location
1 001-MCM66K-0M2 P.C.B MCM66K RECORDING S-SIDE
BOARD REV-0
1pc
2 005-S102B-013 CHIP RESISTOR 1 K (0603) +/-5% 1
p
c R228
3 005-S103B-013 CHIP RESISTOR 10 K (0603) +/-5%
1/16W
4 pcs R229,R230,R232,R235
4 005-S104B-013 CHIP RESISTOR 100K (0603) +/-5%
1/16W
1 pc R231
5 005-S123B-013 CHIP RESISTOR 12K (0603) +/-5%
1/16W
2 pcs R211,R212
6 005-S302B-013 CHIP RESISTOR 3K (0603) +/-5% 2
p
cs R223,R224
7 005-S303B-013 CHIP RESISTOR 30K (0603) +/-5%
1/16W
2 pcs R240,R241
8 005-S333B-013 CHIP RESISTOR 33K (0603) +/-5%
1/16W
2 pcs R215,R216
9 005-S392B-013 CHIP RESISTOR 3.9 K (0603) +/-5%
1/16W
3 pcs R221,R222,R226
10 005-S472B-013 CHIP RESISTOR 4.7K (0603) +/-5%
1/16W
3 pcs R209,R210 R227
11 005-S473B-013 CHIP RESISTOR 47K (0603) +/-5%
1/16W
2 pcs R213,R214
12 005-S681B-013 CHIP RESISTOR 680 OHM (0603) +/-
5% 1/16W
2 pcs R217,R218
13 005-S682B-013 CHIP RESISTOR 6.8K (0603) +/-5% 2
p
cs R219,R220
38
Description : RECORDING (SMT) BOARD ST (DAEWOO-1客戶) Verified Date : 01/18/2006
Model No : TP-501G Page : 1
Part No : BCW138AR-A301 Status : MP(量產)
