Item No description Specification QTY Unit Location
M01-201-MP3018 inserted part of CD-018 1 pcs
M01-301-MP3018
mainboard/recording
board of CD-018
1 pcs
P02-035-0241 P.C.B
018-VCD/MP3-01 MAIN BOARD 150*136.6MM
1 pcs
P02-016-0004
ａｕｄｉｏｎ
9018H NPN
２
pcs
Q2. Q3
P02-010-0006 constant voltage diode 3.9v, 1/2w
１
pcs
Z1
P02-010-0001 constant voltage diode 5.1v, 1/2w
１
pcs
ZD3
P02-010-0002 constant voltage diode 5.6v,1/2w
２
pcs
Z2. Z3
P02-010-0005 DIODE in4148
１２
pcs
D1.D14.D17.D9.D10.D11.
D8.D4.D2.D3.D25.D24
P02-009-0001 FM coil dia5mm*41/2T(0.7mm)
１
pcs
L2
P02-009-0006 FM coil dia4.5mm*31/2T/(0.7mm)
１
pcs
L1
P02-009-0003 FM coil dia4.5mm*21/2T/(0.7mm)
１
pcs
L3
P02-008-0001 inductance 15UH 4*6MM
１
pcs
L4
P02-001-0001 RESISTOR 1/8w,1 ohm 1 pcs
R14
P02-086-0002 COPPER WIRE DIA: 0 . 5 X 10mm 2 PCS
R39
P02-001-0002 RESISTOR 1/8w 10 ohm 6 pcs
R19.R34.R33.R72.R59.R67
P02-001-0003 RESISTOR 1/8W 22 ohm 2 pcs
R85.R42
P02-001-0004 RESISTOR 1/8W 47 ohm 2 pcs
R31.R7
P02-001-0006 RESISTOR 1/8W 100 ohm 3 pcs
R3.R47.R57
P02-001-0009 RESISTOR 1/8W 220 ohm 2 pcs
R28.R56
P02-001-0010 RESISTOR 1/8W 330 ohm 2 pcs
R4.R38
P02-001-0011 RESISTOR 1/8W 560 ohm 4 pcs
R103.R13.R6.R29
P02-001-0050 RESISTOR 1/8W 1k ohm 10 pcs
R18.R22.R46.R24.R25.
R32.R104.R108.R37.R21
P02-001-0013 RESISTOR 1/8W 2.2k ohm 4 pcs
R110.R40.R30.R98
P02-001-0014 RESISTOR 1/8W 3.3k ohm 1 pcs
R97
P02-086-0003 COPPER WIRE DIA: 0 . 5 X 7.5mm 6 PCS
p02-001-0015 RESISTOR 1/8W 4.7k ohm 5 pcs
R117.R105.R12.R80.R119
p02-001-0016 RESISTOR 1/8W 5.6k ohm 3 pcs
R5.R51.R52
p02-001-0017 RESISTOR 1/8W 6.8k ohm 2 pcs
R8.R9
p02-001-0018 RESISTOR 1/8W 10k ohm 13 pcs
R84.R48.R106.R99.R100.
R10.R11.R115.R101.R81.
R101.R41.R96
p02-001-0020 RESISTOR 1/8W 22k ohm 3 pcs
R109.R49.R50
P02-001-0021 RESISTOR 1/8w 39k ohm
１
pcs
R1
P02-001-0109 RESISTOR 1/8w 47k ohm
５
pcs
R45.R23.R53.R113.R111
P02-001-0023 RESISTOR 1/4w 100k ohm
４
pcs
R17.R112.R35.R36
p02-004-0017 CERAMIC CAPACITOR 3pf 2 pcs
C62.C14
p02-004-0002 CERAMIC CAPACITOR 5pf 1 pcs
C61
P02-086-0010 COPPER WIRE DIA: 0 . 5 X 6mm 5 PCS
p02-004-0003 CERAMIC CAPACITOR 18pf 1 pcs
C11
p02-004-0004 CERAMIC CAPACITOR 22pf NP0±5% 1 pcs
C10
P02-004-0005 CERAMIC CAPACITOR 30pf
４
pcs
C1.C2.C5.C58
P02-004-0007 CERAMIC CAPACITOR 100pf
１
pcs
C57
P02-004-0008 CERAMIC CAPACITOR 150PF 1 pcs
C15
9.PART LIST
