Item No description Specification QTY Unit Location
9.3 PART LIST
M01-303-MP3018 MP3-018 LCD pcb parts
１
pcs
P02-023-0001 lighting diode dia 3mm,red 3v =30mm
１
pcs
ＬＥＤ３
P02-002-0072 ELECT. CAPACITOR 100UF 10V(4*7MM)
１
pcs
C80
P02-001-0006 RESISTOR 1/8W 100 OHM
１
pcs
R54
P02-001-0002 RESISTOR 1/8W 10 OHM
２
pcs
R44.R43
P02-001-0005 RESISTOR 1/8W 56 OHM
１
pcs
R55
P02-001-0010 RESISTOR 1/8W 330 OHM
３
PCS
R58
P02-001-0015 RESISTOR 1/8W 4.7K OHM
１
PCS
R20
P02-088-0002
ｅｍｉｓｓｉｖｅ ｐｉｐｅ
DIA.3MM
１
PCS
P02-088-0001 remote RECEIVER 7.6*7.2*5.2MM 5V
１
PCS
IR1
P02-023-0004 lighting diode dia 3mm,Green 3v L=28mm
１
pcs
ＬＥＤ３
P02-011-0004 IC SC3610D 1 pcs
IC3
P02-011-0009 IC 1621 1 PCS
IC4
P02-006-0001 crystal monofier 32.768MHZ,2LEADS,3*8MM
１
PCS
X1
P02-004-0005 CERAMIC CAPACITOR 30pf 2 pcs
C46.C47
P02-004-0016 CERAMIC CAPACITOR 104pf 4 pcs
C48.C86.C83.C79
P02-002-0006 ELECT. CAPACITOR 47UF 16V(4*7MM)
１
pcs
C94
M01-304-MP3018
MP3-018 EARPHONE
pcb parts
1 pcs
P02-001-0008 RESISTOR 1/8W 150 OHM
２
PCS
R15.R16
P02-007-0004 I.F.I 100:10T RED,DIA 7MM, (7*7*11MM) 1 pcs
T3
P02-007-0002 I.F.I pink 7T ,DIA 7MM (6MM) 1 pcs
T2
P02-032-0007 SOCKET vertical,2.00mm,5pin, 1 pcs
cn9
P02-032-0013 SOCKET vertical,2.00mm,8pin, 1 pcs
cn10
P02-008-0005
ｍａｇｎｅｔｉｃ ｉｎｄｕｃｔａｎｃｅ
22UH 3.5*3MM 3T5 2 pcs
L5.L6
P02-032-0009 SOCKET vertical,2.00mm,4pin, 1 pcs
cn11
P02-086-0002 COPPER WIRE dia:0.5*10mm
１
pcs
P02-086-0003 COPPER WIRE dia:0.5*7.5mm 6 pcs
P02-086-0010 COPPER WIRE dia:0.5*6mm
５
pcs
P02-086-0004 COPPER WIRE dia:0.5*5mm 3 pcs
P02-005-0001 FM CERAMIC filter L10,7A(MHZ) 3LEG 1 pcs
IFT1
P02-006-0003 oscillator 455E(KHZ) 2LEG
１
PCS
CF1
P02-005-0002 AM CERAMIC filter 455b(Kmhz) 3 LEG 1 pcs
IFT2
P02-007-0018 I.F.I YELLOW 157:15 DIA (7*7*6MM) 1 pcs
T1
M01-202-MP3018 MP3-018 accessory parts 1 pcs
P02-023-0009 LED 3 COLOR DIA.5MM L=25MM 3V L5R085B20G21Y4M
１
pcs
ＬＥＤ２
P03-053-0007 radiator #CD11
１
pcs
ＩＣ１
P02-019-0011 rolling potentiometer WHO122-02 #CD18B CR9 CD16
１
pcs
P02-022-0002 LCD display #VCD828 translucent 28PIN
１
pcs
P02-030-0007 the speaker wire dia:3.5mm,1m
２
pcs
P02-029-0015 PVC WIRE 100mm.black 26# 2 pcs
speaker box（-） to athorn (-
)x2
P02-029-0014 PVC WIRE 100mm,red 26# 3 pcs
battery sheet(+) to AC
socket1, speasker box (+) to
althorn capacitance 2
P02-029-0001 PVC WIRE 150mm,red 26# 1 pcs
motor + o mainboard
21
