CF65/75/85 series Eaton FS/6309A gearbox
TECHNICAL DATA
7-1
7. EATON FS/6309A GEARBOX
7.1 GENERAL
Gearbox type
Each gearbox has a type-plate attached to it,
indicating the type of gearbox. This data is also
stated on the identity card of the relevant
vehicle.
Eaton gearbox type-plate
1. Type of gearbox
2. Specification no. Eaton
3. DAF article Eaton code
4. Series no. Eaton
5. Production date code
The Eaton specification number is unique for
each customer and gives detailed information on
the development level of the gearbox.
The number must be quoted whenever
replacement parts are ordered.
Input shaft play adjusting rings: Colour coding:
3.70 mm Red, green, white
3.75 mm Yellow, green, blue
3.80 mm Blue, green, white
3.85 mm Red, green, yellow
3.90 mm Green, green, white
3.95 mm Red, green, red
Secondary shaft pre-load
New bearings 0.075 - 0.125 mm
Original bearings 0.000 - 0.050 mm
Sealant
Sealing compound for seal contact surfaces of
drive flange oil seal housing
Loctite 518
Input shaft Lithium-based grease, class NLGI 3
Filter/governor
Governed pressure 5.3 - 5.7 bar
ᓻ 200337
