TECHNICAL DATA
Eaton FS/6309A gearbox CF65/75/85 series
7-2
7.2 TIGHTENING TORQUES
The tightening torques stated in this section are
different from the standard tightening torques
included in the overview of standard tightening
torques.
Any other threaded connections that are
not specified must therefore be tightened to the
torque stated in the overview of
standard tightening torques.
When attachment bolts and nuts are to be
replaced, it is important that they are of exactly
the same length and property class as the ones
removed unless stated otherwise.
Drive flange
M39 drive flange nut 650 Nm
(1)
Drive flange oil seal housing attachment bolts 60 Nm
Gearbox front cover
Attachment bolts 37 Nm
Selector shaft housing
Selector shaft housing attachment bolts 37 Nm
(2)
Retaining cover attachment bolts 22 Nm
M8 shifting arm lock nut 25 Nm
M8 shifting arm lock nut 25 Nm
End cover attachment bolts 22 Nm
Bleed valve
Attachment bolts 19 Nm
Bearing cover
Output shaft bearing cover 25 Nm
Air connection banjo bolt 38 Nm
Filter/governor
M6 attachment bolts 13 Nm
Cover 25 Nm
Selector valve
M6 attachment bolts 22 Nm
M16 discharge valve attachment bolts 19 Nm
M8 cover plate attachment bolts 22 Nm
Range-change cylinder
M8 cover plate attachment bolts 17 Nm
M16 nut on piston 105 Nm
0
