3
PNEUMATICALLY ASSISTED GEARBOX CONTROL
(SERVOSHIFT)
General CF65/75/85 series
1-2
Gate selection
Gates are selected mechanically.
To select a gate, move the gear lever to the left
or to the right, which moves the selector shaft to
the left or to the right.
Engaging gears
To engage the gears, move the gear lever
forwards or backwards.
Switching begins mechanically with the
operation of the selector valve in the
Servoshift unit. This valve controls the
double-acting pneumatic cylinder, and the
selection is pneumatically assisted.
Emergency selector
If there is no air pressure, selection can still be
done mechanically, i.e. non-assisted.
3
ᓻ 200337
