3
CF65/75/85 series General
GEARBOX - PNEUMATIC SECTION
1-9
Regardless of any pneumatic command from
the gear lever range-change switch (5), it is now
no longer possible to switch an air pressure to
connection point 26 of the engaging cylinder (2)
and hence to shift to the low range.
Note:
The air supply to the electropneumatic valve (6)
is only available when the gear lever, and hence
also the neutral position valve (1), is in the
neutral position (N).
4
ᓻ 200337
