3
CF65/75/85 series Removal and installation
GEARBOX - PNEUMATIC SECTION
4-1
4. REMOVAL AND INSTALLATION
4.1 REMOVAL AND INSTALLATION, GEAR LEVER SELECTOR VALVE
Removing the gear lever selector valve
1. Disconnect the dust cover from the cab floor
and raise it over the gear lever as high as
possible.
2. Loosen the union nut (1) on the selector
valve.
3. Raise the selector valve (5) slightly from the
gear lever (3), far enough to enable the air
pipes (4) to be disconnected.
4. Raise the coloured rings over the air pipes.
These coloured rings also serve as
markers.
5. Use a small screwdriver to depress the
edge of the air connection, so that the pipes
can be pulled from the switch.
V300143
5
4
3
2
1
ᓻ 200337
