3
CF65/75/85 series Cleaning
GEARBOX - PNEUMATIC SECTION
5-1
5. CLEANING
5.1 CLEANING FILTER/GOVERNOR, EATON FS/6309A
Cleaning filter/governor, Eaton FS/6309A
Note:
The filter must be regularly cleaned with water
and a soap solution. Then blow clean the filter
with compressed air from the inside.
1. Take the pressure off the air pressure
system
2. Remove the plug (5).
3. Remove and wash the filter (2).
4. Clean the filter housing and if necessary
remove the valve.
5. Replace the sealing ring (3) and O-ring (4).
6. Reassemble and reinstall the filter/governor.
6
5
4
3
2
1
10
9
8
V300430
7
4
ᓻ 200337
