3
CF65/75/85 series Removal and installation, gearbox
ZF 6S-850 GEARBOX
4-3
4.2 REMOVAL AND INSTALLATION, DRIVE FLANGE
Removing the drive flange
1. Make a reference mark on the prop shaft
and flange.
2. Detach the prop shaft from the flange and
secure it.
3. Fit special tool (DAF No. 0484977) to hold
the drive flange in position.
4. Remove the attachment bolt and washer.
5. Remove the drive flange from the shaft
using special tool (DAF No. 0484978).
Installing the drive flange
1. Heat the drive flange to a temperature of
max. 120_C.
2. Oil the output shaft lightly and slide the
drive flange over the shaft in its correct
position.
3. Fit special tool (DAF No. 0484977) to the
drive flange.
4. Tighten the attachment bolt to the specified
torque. See “Technical data”.
5. Attach the prop shaft.
V3 00 416
5
