CF65/75/85 series Draining and filling
ZF 6S-850 GEARBOX
5-1
5. DRAINING AND FILLING
5.1 DRAINING AND FILLING, GEARBOX
To prevent skin injury, avoid
unnecessary contact with the
drained oil.
Draining, gearbox
1. Place the vehicle on a level surface.
2. Drain the gearbox at operating temperature
using plug (B).
Filling, gearbox
1. Clean the drain plug and fit it, tightening to
the specified torque. See “Technical data”.
2. Top up oil through the level check/filler
opening (A) until the oil reaches the rim of
the filling opening.
3. After filling the gearbox, tighten the level
check plug to the specified tightening
torque. See “Technical data”.
B
M3038
A
5
ᓻ 0111
