CF65/75/85 series Removal and installation of gearbox
ZF 8/16S-151/181 AND 16S-221 GEARBOXES
4-9
Installing the selector shaft oil seal
1. Fit the bearing bush in the cover using the
special tool (DAF No. 0535659).
2. Apply a thin layer of liquid gasket to the
outer circumference of the first oil seal to be
installed and install it in the cover using the
special tool (DAF No. 0535659).
3. Apply a thin layer of liquid gasket to the
outer circumference of the second oil seal
to be installed and install it in the cover
using the special tool (DAF No. 0535659).
4. Apply a thin layer of grease to the inside of
both oil seals.
5. Install a new gasket and carefully slide the
cover over the selector shaft and
hand-tighten the bolts. Move the selector
shaft from one side to the other several
times, allowing the cover to centre itself.
Tighten the attachment bolts to the
specified torque. See “Technical data”.
6. Fit the dust cap and the selector shaft lever.
Ensure that the dust cap is free of play
relative to the selector shaft lever and fit the
locking bolt and, if necessary, the circlip.
W 3 03 082
7. Install the ball joint of the control rod on the
selector shaft lever and the nut of the torque
rod.
8. Inspect the shift control. See “Inspection
and adjustment”.
V300407
4
5
7
ᓻ 200337
