DAF CF75 Series - Page 246

3
ZF 8/16S-151/181 AND 16S-221 GEARBOXES
Removal and installation of gearbox CF65/75/85 series
4-8
4.5 REMOVAL AND INSTALLATION, SELECTOR SHAFT OIL SEAL
Removing the selector shaft oil seal
1. Remove the ball joint of the control rod on
the selector shaft lever and the nut of the
torque rod.
Hang the control rod on the chassis.
2. Remove the locking bolt and, if necessary,
the circlip from the selector shaft and
remove the selector shaft lever together
with the dust cover.
3. Loosen the bolts of the oil seal cover and
remove the cover.
4. Check the selector shaft for damage. Lightly
sand the shaft, if necessary, with fine
abrasive cloth.
V300407
4
5
5. Remove the oil seals together with the
bearing bush from the cover using the
special tool (DAF No. 0535659).
6. Check the bearing bush for damage.
Replace if necessary.
W 3 03 084
7
ᓻ 200337
