CF65/75/85 series Inspection and adjustment
AUTOMATIC GEARBOXES
3-3
Checking the oil level using the selector
keypad
1. Apply parking brake, put the gearbox in the
neutral position and bring the gearbox to
operating temperature (approx.
71_C-93_C).
2. Run the engine at idling speed for 2
minutes.
3. Press both arrow keys on the selector
keypad simultaneously. The display now
indicates O and L.
Note:
O and L stand for Oil Level.
4. If the oil level is correct, O - K will appear in
the display. When the oil level is too high,
this is indicated by HI followed by the
number of litres in excess. When the oil
level is too low, this is indicated by LO
followed by the number of litres lacking. For
example:
LO-02 means add two litres.
HI-03 means drain three litres.
R
D
MODE
N
V300392
9
ᓻ 200337
