3
AUTOMATIC GEARBOXES
Inspection and adjustment CF65/75/85 series
3-2
Inspection, hot oil level
1. Bring the gearbox to operating temperature
(approx. 71_C-93_C).
2. Remove the dipstick when the engine is
idling and wipe it clean with a lint-free cloth.
Note:
To take the dipstick out of the holder, the
sealing cap must be held tightly and the
dipstick turned anti-clockwise.
3. Put the dipstick back.
4. Remove the dipstick and check the oil level.
5. The oil level must be between the “Hot add”
and the “Hot full” marks.
6. Clean the dipstick with a lint-free cloth and
put it back.
7. Remove the dipstick and check the oil level
again.
8. Oil needs to be added when the oil level is
below the “Hot add” mark.
9. Oil needs to be drained when the oil level is
above the “Hot full” mark.
Note:
The oil level must be checked at least twice.
When there are differences between the
measurements, check the bleeder for
clogging.
9
