CF65/75/85 series Removal and installation
AUTOMATIC GEARBOXES
4-1
4. REMOVAL AND INSTALLATION
4.1 REMOVAL AND INSTALLATION, GEARBOX ASSEMBLY
Removing the gearbox assembly
1. Note:
Before the gearbox can be removed, the
gearbox oil must be drained.
2. If necessary, remove the oil filler pipe to
avoid damage.
3. Plug the external oil pipes after removing
and/or detaching them to prevent dirt
entering the oil system.
4. Disconnect the gearbox cable harness
connectors and secure the cable harness.
Plug the openings.
5. Remove the prop shaft.
6. See what is best for gearboxes with PTO:
remove the PTO from the gearbox,
disconnect the hydraulic pipes from the
pump or remove the prop shaft, if fitted.
7. Remove the gearbox from the engine.
Installing the gearbox assembly
1. Apply grease sparingly to the nose of the
torque converter to prevent noise after
fitting. See “Technical data”.
2. Install the PTO.
3. If necessary, fit the hydraulic pipes and/or
prop shaft.
4. Attach the prop shaft.
5. Connect the cable harness connectors.
6. Fit the external oil pipes.
7. If necessary, fit the oil filler pipe.
8. Fill the gearbox with oil and check the oil
level.
W 3 03 100
ᓻ 200337
