3
AUTOMATIC GEARBOXES
Removal and installation CF65/75/85 series
4-2
4.2 REMOVAL AND INSTALLATION, OUTPUT SHAFT OIL SEAL
Removing the output shaft oil seal
1. Remove the prop shaft and secure it so that
it does not interfere with further operations.
W 3 03 061
2. Unscrew the attachment bolt (5) of the
flange without removing it from the locking
plate.
V300529
1
2
3
5
4
3. Remove the bolt and locking plate from the
flange.
Pay attention to the sealing rings on the
outer circumference and on the inside of the
locking plate.
V300559
9
ᓻ 200337
