3
AUTOMATIC GEARBOXES
Removal and installation CF65/75/85 series
4-4
4. Fit new sealing rings (2, 3) to the locking
plate and fit the locking plate with the
attachment bolt to the flange (apply grease
sparingly to the sealing rings).
Note:
For the new gearboxes the attachment bolts
are no longer locked with a locking plate,
but with self-locking screw thread in the
output shaft.
5. Hold the prop shaft flange in place with the
special tool (DAF No. 0484977).
6. Tighten the attachment bolt (5) to the
specified torque. See “Technical data”.
If the locking plate is not tightened
to the specified torque, there is a
risk of the locking plate getting bent
during fitting, which could lead to
serious oil leakage.
V300530
1
5
4
3
2
9
ᓻ 200337
