3
CLUTCH
Inspection and adjustment CF65/75/85 series
4-2
2. The free travel (B) of the clutch pedal is set
indirectly by loosening the lock nut (2) and
then screwing the ball joint (1) into or out of
the thrust pin (3). This sets the distance (E)
between the thrust pin (3) and the piston (4)
in the main cylinder: see “Technical data”.
V300411
1
E
2
3
4
5
6
7
10
ᓻ 200337
