3
CLUTCH
Removal and installation CF65/75/85 series
5-10
Installing the clutch release assembly/clutch
plate
1. Apply a little grease to the input shaft and
check the movement of the clutch plate on
the splines of the input shaft.
2. Use a dummy input shaft to position the
clutch plate against the flywheel.
3. Install four studs in the flywheel, distributed
evenly around the circumference.
4. Support the clutch release assembly and
slide it onto the four studs.
5. Fit the attachment bolts and tighten them
crosswise and evenly to the specified
torque. See “Technical data”.
6. Apply a little grease to all pivoting points of
the release fork.
7. If necessary, fit the thrust bearing.
8. Fit the gearbox.
10
ᓻ 200337
